5. TAKING A MEASUREMENT
The steps
Measuring the module temperature at several points of the string
or module to be measured (chapter 9.3). It is recommended to
measure the temperature at least 3 times before measuring the
characteristic curve and at least 3 times after.
Fitting the TRI-SEN mounting to the module/string to be meas-
ured and measuring the irradiation (chapter 9.5).
Using the TRI-KA to measure the open-circuit voltage (U ) and
OC
the short-circuit current (I ) and determine the system's current/
SC
voltage characteristic curve (chapter 7.1).
Wireless transfer of the measured data from the TRI-SEN to the
TRI-KA during or after measurement (chapter 10.1).
Importing the measured results via SD card from the TRI-KA into
the PC and evaluating them using the software provided (chapter
10.2).
