Transfer of measuring data_233

10. TRANSFER OF MEASURING DATA

10.1 Transfer of TRI-SEN data to the TRI-KA

The data measured by the TRI-SEN are wirelessly transferred to
the TRI-KA. A wireless connection is automatically established
once both instruments are switched on. The connection is shown
at the top of the screen (picture).
If the wireless connection is disrupted, the data are stored in the
TRI-SEN until they are synchronised. This allows measurement
even without a connection. The disruption of the data connection
is signalled by a message popping up on the TRI-KA screen.
The TRI-SEN should not be switched off before the data have
been transferred, as otherwise all values will be lost and the meas-
urement is no longer reliable.

10.2 Transfer of TRI-KA values to the PC

Once saved, all measured values are automatically stored on the
SD card of the TRI-KA.
The data are uploaded using the TRI-KA PC software and insert-
ing the memory card into the computer or the supplied reader.
More details on how to upload the data are provided in the soft-
ware manual on the SD card.
The software is saved on the SD card of the TRI-KA in the
directory "...\TRI-KA\UPDATE"; it can also be downloaded at
www.tritec-energy.com.
