INSTALL DUST COLLECTION BAG

The tool includes a dust collection bag that attaches
over the exhaust port on the upper blade guard.
To install, slide the plastic collar (D) of the dust bag onto
the dust port (E). See Figure 6
NOTE: To remove the dust bag for emptying, simply
reverse the above procedure.

INSTALL BATTERIES FOR LASER

1. The battery compartment (C) is located in the control
arm on the top of the saw handle.
2. Using the Phillips end of the supplied blade wrench,
remove the screw (D) securing the compartment
cover and lift off the cover.
3. Install two AAA batteries (supplied) as shown on the
diagram in the compartment.
4. Replace the cover and secure with the screw.
Laser radiation. Avoid direct eye
contact with light source.
ASSEMBLY
11
A
B
FIGURE 6
C
FIGURE 7
D
