Function Check

Perform this quick functional check to verify that your scope meter is operating correctly.
1. Turn on the instrument.
Use the power adapter designed for your scope meter only. Use a power source that
delivers I00 to 240 VACRMS, 50Hz. Turn on the scope meter.
2. Input a signal to a channel
Set the attenuation switch on the probe to IOX and connect the probe to Channel I on
the scope meter.
To do this:
■
Align the slot in the probe connector with the key on the CH I BNC connector.
■
Push to connect, and twist to the right to lock the probe in place.
■
Attach the probe tip and ground lead to the PROBE COMP connector.
Set the probe attenuation of the scope meter to I0X.To do this, push CHI→Probe→I0X.
AUTO
Push the button. Within a few seconds, a square wave will display
(approximately I kHz 2 V peak- to- peak).
Turn off Channel I and turn on Channel 2, repeat steps 2 and 3.
©Copyright Abacanto Digital SA.
24
Figure I-5
Set the probe
