3.3 Connecting a sensor
To connect sensors, disconnect the rubber plug from the pH socket. Connect the electrode and make
sure that the plugs are properly inserted. If you are using an electrode with a built-in temperature probe
or a separate temperature probe, connect the other lead to the ATC socket. Twist the RCA (Cinch) plug
to ease the attachment of the sensor.
®
ISM sensor
When connecting an ISM
calibration data to be transferred automatically from the chip of the sensor into the meter and is used
for further measurements. After attaching the ISM
● The meter must be switched on.
● (If the meter is already switched on) the READ key is pressed.
● (If the meter is already switched on) the CAL key is pressed.
We strongly recommend you to switch off the meter when disconnecting an ISM sensor. In doing so,
you make sure that the sensor is not removed while the instrument is reading data from or writing data
to the ISM-chip of the sensor.
The ISM icon appears on the display and the sensor ID of the sensor chip is registered and
appears on the display.
The calibration history, the initial certificate and the maximum temperature can be reviewed and print­
ed in the data memory.
®
sensor to the meter, one of the following conditions have to be met for the
®
sensor ...
Installation 11
