Use instructions for NIOSH-approved full facepieces

Cleaning and Disinfecting

The facepiece must be cleaned after every use so that it is clean
before it is used by a different individual or, if individually assigned, as
often as necessary to keep in a sanitary condition. Facepieces that
are issued to more than one user must be cleaned before being worn
by different individuals.
The facepiece must be disinfected after every use to keep it in a san-
itary condition. It is fully in the user's responsibility to make sure that
the facepiece is totally free of contaminants after this treatment.
Never use a facepiece again, that has not been properly disinfected.
In case of doubts dispose of the facepiece in accordance with the
local regulations and use a new one.
The facepiece body must be cleaned thoroughly so that no residues
from skin care products remain on it.
Otherwise the elasticity in the sealing area can be lost and the
facepiece will no longer fit correctly.
Failure to take note of this warning can result in poisoning or death.
Do not use any solvents (e.g. acetone, alcohol) or cleaning agents
containing abrasive particles for cleaning and disinfecting. Only use
the methods and the approved cleaning and disinfecting agents
described in this section. Other methods or agents can cause dam-
age to the product.
Undiluted agents that come into direct contact with eyes or skin are
hazardous to health. Always wear suitable protective equipment
when working with the cleaning and disinfecting agents described
in this section.
Since the use of certain cleaning and disinfecting agents is not
allowed among all countries, Dräger tested and recommends sev-
eral cleaning and disinfecting agents. However, Dräger makes no
representations that such agents comply with or are approved for
use in your specific country's regulations. Make sure to follow the
procedure that is suitable for your country.For further information
please contact Dräger or your local dealer.
Cleaning and Disinfecting Procedure
Remove any accessories from the facepiece and clean them sepa-
•
1)
rately .
Clean all parts with lukewarm water and 1008 GREEN LIQUID
•
HAND DISH WASH using a soft cloth.
Thoroughly rinse all parts under running water.
•
Prepare a disinfectant bath containing water and 800 SPUR-TEX
•
Disinfectant (max. temperature: 86 °F/30 °C, concentration: 2 fl.oz.
per 1 gallon/60 ml per 3.79 l).
Place the parts to be disinfected into the disinfectant bath (duration:
•
15 minutes).
Thoroughly rinse all parts under running water.
•
Dry all parts in the air or in a drying cabinet (max. temperature:
•
140 °F/60 °C). Do not expose to direct sunlight. Do not shake the
facepiece in order to remove water.
Mount the accessories if necessary.
•
1) Strictly follow the corresponding Instructions for Use.
28
WARNING
CAUTION
NOTICE
Alternative Cleaning and Disinfecting Procedure
Remove any accessories from the facepiece and clean them sepa-
•
2)
rately .
Prepare a cleaning solution containing water and NEUTRAL DISIN-
•
FECTANT CLEANER (max. temperature 86 °F/30 °C, concentra-
tion: 1 fl. oz. per 2 gallons/30 ml per 7.57 l).
Immerse the facepiece in the solution (duration: 10 minutes). Make
•
sure that all parts are wetted.
Thoroughly rinse all parts under running water.
•
Dry all parts in the air or in a drying cabinet (max. temperature:
•
140 °F/60 °C). Do not expose to direct sunlight. Do not shake the
facepiece in order to remove water.
Mount the accessories if necessary.
•

Visual Inspection

Check if the full-face mask is complete and functions correctly.
•
Check the exhalation valve:
•
Remove the protective cap from the mask connector and pull
•
out the valve disc.
The valve disc and seat must be clean and undamaged.
Clean or replace if necessary. Moisten the valve disc with water
•
before fitting it.
Maintenance
Carry out both a visual inspection and a leak test after any mainte-
•
nance work.
Replacing the lens
Mask with metal lens frame: Grip the hexagonal nuts and unscrew
•
the screws.
Mask with plastic lens frame: Unscrew the screws. Pry the lens
•
frame apart with a screwdriver at the connecting points, then pull it
off to the top and bottom.
Remove the connector clamp, sliding ring and support if necessary.
•
Detach the old lens from its rubber frame.
•
Insert a new lens, first in the upper half and then in the lower half of
•
the rubber frame.
The center marks on the lens must be aligned with the seam on the
facepiece.
Draw the rubber frame over the edge of the lens on the right and
•
left.
Moisten the outside of the rubber frame and the inside of the lens
•
frame with soap solution.
Fit first the upper, then the lower lens frame.
•
Put support between connector clamp and sliding ring if necessary,
•
clamp it to the bottom lens frame and align it.
Mask with metal lens frame: Screw the screws into the hexagonal
•
nuts and tighten until the gap between the clamp lobes is between
3 and 0.5 mm.
Mask with plastic lens frame: Insert and tighten the screws.
•
Replacing a control valve disc
Pull out the old valve disc towards the inside.
•
Insert the stud of the new disc into the hole from inside, and pull it
•
towards the lens until the undercut of the stud is visible.
The valve disc should make even contact with the inside surface.
Replacing the exhalation valve disc
Remove the protective cap from the mask connector.
•
Pull out the valve disc.
•
The valve disc and seat must be clean and undamaged. Clean or
replace if necessary.
Moisten valve disc with water and refit.
•
Refit the protective cap so that it engages.
•
Replacing an inhalation valve disc
Pull the inhalation valve out by its edge.
•
Remove the old valve disc and fit new disc.
•
Stretch and press the inhalation valve disc around the stem until it
•
makes even contact all around.
The valve disc must not be pinched. The disc must face inwards,
and the stems face outwards.
2) Strictly follow the corresponding Instructions for Use.
