Using the Harness Buckle

To Fasten:
1. Insert one tongue at a
time into the buckle.
Proper connection is
confirmed with a click
after inserting each
buckle tongue.
To Release:
1. Press the release button
and pull the tongues from
the buckle.
NOTE: Periodically clean
the buckle to ensure
proper operation. See
page 39.

Using the Chest Clip

1. Open the chest clip.
a. Press tabs.
b. Pull apart.
2. Push together
to fasten.
NOTE: Always
position the
chest clip at
armpit level.

Using the Lock-Offs

To Open:
1. Open the locking tab.
2. Open the clamp.
IMPORTANT: Both parts
of the lock-off must be
opened to secure a vehicle
belt.
24
b
a
1
LOCKING
TAB
2
CLAMP
To Close:
1. Close the clamp over the
vehicle belt.
2. Push down on the locking
tab where indicated until
a click is heard.

Infant Positioning Pillow

The infant positioning pillow
is designed to provide better
harness fit and comfort for
infants using this child seat.
IMPORTANT: The infant
positioning pillow must be
used with infants weighing up
to 22 lbs (10 kg) when using
a child seat in a rear-facing
position. Do not use over 22 lbs
(10 kg) or in a forward-facing position.

Seat Positions

This child seat has 3 positions. To adjust, pull the recline
handle then rotate the child seat shell into the desired
position. Release the recline handle, then verify the child
seat has locked into position.
NOTE: Set the seat position BEFORE installing.
0°
90°
90°
Position 1 Position 2
Rear-Facing
When properly installed in the rear-
facing position, the back angle of the
child seat should be at least 30˚ for
children and up to 45˚ from vertical for
infants unable to maintain head and
neck control (not to exceed 45˚) when
the car is parked on a level surface.
Use the line as a guide to achieve the proper recline angle
for rear-facing installations. The line will be parallel to the
ground when the child seat angle is at the center of the
acceptable angle range (37.5˚). If necessary, the proper
recline angle can be achieved by placing a rolled towel or
pool noodle in the vehicle seat bight.
ROUNDABOUT User Guide
Locking
2
Vehicle
Tab
Belt
1
Clamp
0°
0°
90°
Position 3
30˚
0˚
90˚
45˚
25
