5 Human machine interface (HMI)
Local PSTX30
Motor current
0.0
B
Motor current
0.0
Options 12:00
D
Stop
G H I
F
Figure 1: HMI
10 Softstarters Type PSTX30...PSTX1250 User Manual short form 1SFC132082M9901
Refer to figure 1 for the HMI parts:
A
A Display for information.
Left selection soft key. The function is
B
showed to the left in the display above the
A
key.
C
%
Right selection soft key. The function is
C
showed to the right in the display above the
key.
Menu
Left LED indicators.
D
Ready (green) and Run (green).
E
Right LED indicators.
E
Protection (yellow) and Fault (red)
Navigation keys. To navigate in the menu
F
Start
and change the parameter values.
Highlighted black board on numbers or text
shown in the display indicates that the
J K menu/value can be changed or scrolled
Remote/local-key. Switch between local
G
control from the HMI and remote control
from hardwire input or fieldbus.
Stop-key. Stop-switch for the softstarter.
H
To stop the motor according to the set
parameters.
(Only active in local control mode).
Mini USB port. For communication with
I
external devices, eg. a PC.
Start-key. Start-switch for the softstarter.
J
To start the motor and operate it according
to the set parameters.
(Only active in local control mode).
Information-key. For context-sensitive
K
information about the softstarter status and
settings.
Refer to the timing diagram in graphics 13
for the basic behaviour of PSTX softstarter.
