Válvula ED
Febrero de 2020
Clave Descripción
Cuerpo de la válvula
(figuras 19 - 24)
1
Valve Body
If you need a valve body as a replacement
part, order by valve size, serial number,
and desired material.
2*
Valve Plug
3*
Cage
4
Cage Adaptor
5
Seat Ring Adaptor
6*
Piston Ring(s)
7*
Valve Plug Stem
8*
Pin
9*
Seat Ring
9*
EAD liner
10* Bonnet Gasket
11* Cage Gasket
12* Spiral Wound Gasket
13* Seat Ring Gasket
14* Adaptor Gasket
15
Cap Screw
15
Stud Bolt
16
Hex Nut
30
Clave Descripción
17
Pipe Plug, for use in valves with drain tapping only
18
Flow Direction Arrow
19
Drive Screw
20* Adaptor Gasket
26
Load Ring
27* Shim
31* Whisper Trim III Cage Retainer for
Levels A3, B3 & C3 (NPS 6 ED only)
31* Whisper Trim III Cage Retainer & Baffle
Ass'y for Level D3 (NPS 6 ED only)
32
Whisper Trim III Bonnet Spacer
51* Shim
54
Wire
Internos C-seal (figura 6)
2*
Valve Plug/Retainer
3*
Cage
6*
Piston Ring
7*
Valve Plug Stem
9*
Seat Ring
64*
C‐seal
*Piezas de reemplazo recomendadas
Manual de instrucciones
D100390X0ES
