Situation
Restricted operation or charging not possible
(message on display).
The charging current is too low (message on display).
The grid voltage is too high (message on display).
The charger is not within the permitted temperature
range (message on display).
The circuit breaker in the domestic installation was
triggered (message on display).
Moving and Storage
Instructions
Do not lift, carry or move the charger by the supply
cable, vehicle cable, power plug or vehicle plug.
Always lift, carry and move the whole device.
Do not damage the control unit, cables or plugs when
moving, e.g. by dragging over the floor or
sharp edges.
Proper storage: Store in a cool dry place away
from direct sunlight: not below –22 °F (–30 °C) or
above +122 °F (+50 °C).
Recommended action
e Make sure that the supply and vehicle cables are connected to the control unit on the correct side and are
plugged in correctly at the connections.
e Make sure that the charger is within the permitted temperature range.
Refer to chapter "Technical Data" on page 18.
e Acknowledge any error message that appears.
e Start the charger again. Press the Power button for at least 10 seconds to start the charger again.
e The home network is overloaded. Switch off other high-usage electrical loads.
e Have the domestic installation checked by a qualified electrician.
e Device temperature switch-off: Avoid direct sunlight and let the charger cool down slowly by itself.
e Low-temperature switch-off: Let the charger heat up in a warm environment before using it.
e Device temperature sensor faulty: Have the charger replaced.
e Reduce the charging current in the settings on the charger.
e Acknowledge any error message that appears.

Transport

Unsecured load
WARNING
An unsecured, incorrectly secured or incorrectly
positioned charger can slip out of place and endanger
occupants when braking, accelerating, changing
direction or in the event of an accident.
e Never transport the charger unsecured.
e Always transport the charger in the luggage
compartment, never in the passenger
compartment (e.g. on or in front of the seats).

Moving and Storage Instructions

Securing the charger during
transport
The charger is supplied with or without a transport
case, depending on the vehicle type.
e If a transport case is supplied: Always stow and
transport the charger in the case. Attach the case
to the front and rear tie-down rings with hooks.
For information on the tie-down rings in the
luggage compartment:
f see Owner's Manual.
e If a transport case is not supplied: Stow the
charger in the rear luggage compartment while
transporting it.
e Depending on the vehicle type, stow the charger
in such a way that it does not endanger any
occupants in dangerous situations.
