11.7.5

Setting the measurement range

All parameters for configuration of the measuring range can be set with the
measurement range wizard.
1. Select [Docking Station] > [Module] > [Port].
2. Select
 The measured gas setting wizard is displayed.
3. Enter the parameters.
4. Confirm the selection with
11.8

Displaying the Dashboard view

The Dashboard view presents the system's Dashboard screen with the full range of
functions for operating the system. The function is exited after 15 minutes of
inactivity.
Requirements:
– System is connected to the PC.
– Configuration interface is configured.
1. In the toolbar, select
menu bar.
2. A window with the Dashboard view is displayed.
11.9

Selecting the PC interface

1. In the menu bar, select Settings > Network adapter....
 A dialogue window is displayed.
2. In the Select network adapter dialogue window, select the desired PC interface
and confirm with
Dräger recommends disabling all network services and TCP/IP stacks for the
Ethernet connection to the system. To retain this setting, a dedicated Ethernet
connection with a USB Ethernet adapter should be used.
11.10

Change language of the configuration software

1. In the menu bar, select Settings > Language.
2. Select the required language.
12

Interlinking with REGARD 7000

The REGARD 3000 can be connected to an existing REGARD 7000 as a satellite
system. The REGARD 3000 then functions as an additional Docking Station for the
REGARD 7000.
|
Instructions for use
REGARD 3000
> Measurement range assistant.
.
or select Maintenance > Dashboard view... in the
.
Interlinking with REGARD 7000
|
en
179
