Stopping the Engine

1.Turn off and unplug all electrical loads.Never start
or stop the generator with electrical devices plugged
in or turned on.
2.Let the generator run at no-load for several
minutes to stabilize internal temperatures of the
engine and generator.
3. Turn the ignition switch to the "Off" position.
4.Turn the fuel valve to the "Off" position.

Do Not Overload Generator

Capacity

Follow these simple steps to calculate the running
and starting watts necessary for your purposes.
1. Select the electrical devices you plan on running
at the same time.
2. Total the running watts of these items.
This is the amount of power you need to keep your
items running.
3. Identify the highest starting wattage of all devices
identified in step 1. Add this number to the number
calculated in step 2.
2. Surge wattage is the extra burst of power needed
to start some electric driven equipment. Following
the steps listed under "Power Management" will
guarantee that only one device will be starting at a
time.

Power Management

Use the following formula to convert voltage and
amperage to watts:
Volts x Amps = Watts
To prolong the life of your generator and attached
devices, follow these steps to add electrical load:
1. Start the generator with no electrical load
attached.
2. Allow the engine to run for several minutes to
stabilize.
3.Plug in and turn on the first item. It is best to attach
the item with the largest load first.
4.Allow the engine to stabilize.
5.Plug in and turn on the next item.
6. Allow the engine to stabilize.
7. Repeat steps 5-6 for each additional item.
?
NOTE
Never exceed the generator capacity when
adding loads.
Tel: (888)696-2345

Wattage Reference Chart

Use the chart to determine approximate wattage
requirements for your equipment.
?
NOTE
Starting watts can exceed three times the
running watts. The values in the following table
are approximate. Refer to your tool or appliance
for actual wattage consumption.
Item
Light Bulb 100W
Refrigerator/Freezer
Freezer
Sump Pump
Well Pump 1 HP
Water Heater
Security System
AM/FM Radio
Garage Door Opener 1/2 HP
Battery Charger 12V DC
Air Conditioner 12000 BTU
Fan
Furnace Fan 1/3 HP
Microwave 1000W
Electric Range - One Element
Electric Skillet
Coffee Maker
Clothes Washer
CD/DVD Player
VCR
Stereo Receiver
Television 27"
PC with 15" Monitor
Belt Sander 3"
Bench Grinder 6"
Circular Saw
Compressor 1 1/2 HP
Edge Trimmer
Hand Drill 1/2"
Lawn Mower
Paint Sprayer
Table Saw
Web Site: easterntools.com
Running
Watts
Essentials
100
1200
500
600
2000
4000
180
300
500
110
Heating/Cooling
1700
300
1200
Home Appliances
1000
1500
1250
1500
1200
Entertainment
100
100
450
500
800
Job Site
1000
700
1500
2500
500
1000
1200
600
2000
Starting
Watts
2400
500
1800
4000
600
2500
600
2000
1500
1500
1500
2500
500
1000
1800
1200
2000
