Frequency measurement
Range
60.00 Hz
600.0 Hz
6.000 kHz
60.00 kHz
600.0 kHz
6.000 MHz
10.00 MHz
Sensitivity:
o >2 V RMS for 20...80% of duty cycle and <100 kHz
o >5 V RMS for 20...80% of duty cycle and >100 kHz
Overload protection: 1000 V DC/AC RMS
Duty cycle measurement
Range
10.0... 90.0%
Pulse amplitude: ±5 V
Pulse width: 0.1 ms...100 ms
Frequency: 40 Hz...10 kHz
Overload protection: 1000 V DC/AC RMS
Temperature measurement
Range
-40.0...+1000C
-40.0...+1832F
The accuracy of the temperature probe is not taken into account
Overload protection: 1000 V DC/AC RMS
72
Resolution
0.01 Hz
0.1 Hz
0.001 kHz
0.01 kHz
0.1 kHz
0.001 MHz
0.01 MHz
Resolution
0.1%
Resolution
0.1 or 1C
0.1 or 1F
CMP-1015-PV – USER MANUAL
Accuracy
 (0.2% m.v. + 5 digits)
Accuracy
 (1.2 % m.v. + 8 digits)
Accuracy
± (1.5% m.v. + 3C)
± (1.0% m.v. + 5.4F)
