17 Scene Button
18 Page Button
19 Dmx Fog Ma-
chine Button
20 Number Buttons
1 to 15
21 USB Port
22 Power On/Off
23 Power Input
24 Fuse
25 Microphone for
sound control
26 Dmx512 Output
• When this button is activated (LED lights), the number
buttons (20) store and activate scenes.
To switch the number buttons (20) between the two
•
memory pages in CHASE or SCENE mode.
LED A lights: page A (memory location 1-15) is selected.
•
LED B lights: page B (memory location 16-30) is sel.
•
To activate a connected fog machine.
•
These buttons control different functions depending
•
on the selected mode and have a dual occupancy; the button
PAGE (18) allows switching between the two memory pages in
CHASE or SCENE mode.
Movement: To activate and deactivate movements
•
(button 1-9) or color effects (button 10-15).
Chase: To store and activate chases.
•
Scene: To store and activate scenes.
•
For connecting a USB flash drive for storing and import-
•
ing data and firmware updates.
• Switches the controller on and off.
Plug in the mains cable here.
•
Only replace the fuse when the device is disconnected
•
from mains. Only use fuses of the same rating and power. The
correct fuse value is specified on the rear panel.
• 3-pin XLR jack for connecting the DMX input of the first
light effect unit.
