B. Transmitter position
C. Probe frequency
Follow the transmitter position (B). Watch as the signal strength increases by both the numeric
indicator. Also note the audible indicator as you get closer to the transmitter / SONDE.
C
A. Signal strength
B. Transmitter position
C. Probe frequency
When you have arrived at the location with the greatest signal strength (forward/ backward/ left/
right), the transmitter position (B) is in the center of the screen.
B
A depth measurement can now be carried out.
4

Care and Maintenance

Always clean ROCAM mini HD AMPShare after every pipe inspection!
 Turn ROCAM mini HD AMPShare off with the power button on the monitor and remove the
battery.
 Take off the reel (6) from the ROCAM mini HD AMPShare and clean under running water.
 Only clean the reel when removed from the ROCAM mini HD AMPShare.
ROCAM mini HD AMPShare must be protected against water and must only be cleaned
with a damp cloth!
 Insert dried reel back into the ROCAM mini HD AMPShare.
