CEILING RECESS INSTALLATION INSTRUCTIONS CONTINUED ...
13.Once all connections have been made, use the supplied
4x M4x8mm screws to close the terminal box.
MIN 2 PEOPLE REQUIRED
FOR FOLLOWING STEPS.
MAX SAFE LIFTING 16 kg
(26.5 lbs) PER PERSON.
14. Bring the heater and terminal box up onto stable work
platform closer to the terminal box cut-out end.
IMPORTANT
ENSURE THE FRONT GLASS OF THE
HEATER IS PROTECTED BEFORE
PLACING ON TOP.
15. Before installing the terminal box - retrieve the thermal
cut-off switch cable.
Plug it into thermal cut-off switch receptacle at the rear of
the terminal box.
WARNING
Heater will not function unless the
thermal cut-off switch plug is inserted
into receptacle on rear of terminal box.
16. Fasten the terminal box into the ceiling recess box using
4x M4x8mm screws.
