Technical Data; Remote Control - LaserLiner Quadrum Compact Manual Del Usuario

Technical data

Self-levelling range
Accurancy
Levelling
Self-levelling alignment time
Rotation speed
Laser wavelengths red / green 635 nm / 515 nm
Laser wavelengths
Reference beam red / green
Laser class
Power supply
Operating time red / green
Charging time
Operating conditions
Storage conditions
Protection class
Dimensions (W x H x D)
Weight

Remote control

Power supply
Remote control range
Weight
26
EN
(Subject to technical alterations. 24W25)
± 4°
± 0.15 mm / m
automatic horizontal / vertical levelling
approx. 30 seconds over the entire
operating angle
0, 300, 600 rpm
650 nm / 515 nm
2 / < 1 mW (EN 60825-1:2014/A11:2021 /
EN 50689:2021)
Li-ion battery pack 7.4V / 2.6Ah / 19.24Wh
approx. 25 h / approx. 23 h
approx. 4 h
-10°C ... 50°C, max. humidity 80% rH, no
condensation, max. working
altitude 4000 m above sea level
-10°C ... 70°C,
max. humidity 80% rH
IP 66
170 x 188 x 170 mm
1,575 g (incl. battery pack)
2 x 1.5V LR6 (AA)
max. 30 m (IR-control)
146 g (incl. batteries)
