VERTICAL EXHAUST INSTALLATION
WALL
CONNECT TO
TUMBLER
2" (5.1 cm)
MINIMUM
WALL
2" (5.1 cm)
MINIMUM
NO SCREEN
OR CAP
AIR OUT
DUCT
30 LB. 28" WIDE
STATION
GAS & ELEC.
A 7" (17.8 cm)
B 10" (25.4 cm)
C 12" (30.5 cm)
14" (35.6 cm)
D
16" (40.6 cm)
E
F 18" (45.7 cm)
G 19" (48.3 cm)
H 20" (50.8 cm)
I 22" (55.9 cm)
J 23" (58.4 cm)
K 24" (61.0 cm)
L 25" (63.5 cm)
M414670
© Published by permission of the copyright owner – DO NOT COPY or TRANSMIT
NOTE: WHERE THE EXHAUST DUCT PIERCES A COMBUSTIBLE WALL
OR CEILING, AN OPENING HAVING A DIAMETER FOUR INCHES (10.2 cm)
LARGER THAN THE DIAMETER OF THE EXHAUST DUCT SHALL BE
PROVIDED, AND THE EXHAUST DUCT CENTERED WITHIN THE OPENING.
L K
30, 50, 75 LB.
GAS & ELEC.
10" (25.4 cm)
12" (30.5 cm)
15" (38.1 cm)
17" (43.2 cm)
19" (48.3 cm)
21" (53.3 cm)
23" (58.4 cm)
25" (63.5 cm)
26" (66.0 cm)
27" (68.6 cm)
29" (73.9 cm)
30" (76.2 cm)
HORIZONTAL EXHAUST INSTALLATION
CONNECT TO
TUMBLER
EXHAUST AIR FLOW
MAXIMUM LENGTH OF
DUCT 14 FEET
(4.3 m)
NOTE: WHERE THE EXHAUST DUCT PIERCES A COMBUSTIBLE WALL
OR CEILING, AN OPENING HAVING A DIAMETER FOUR INCHES (10.2 cm)
LARGER THAN THE DIAMETER OF THE EXHAUST DUCT SHALL BE
PROVIDED, AND THE EXHAUST DUCT CENTERED WITHIN THE OPENING.
Figure 4
J I H G F
MINIMUM DIAMETER
30, 50, 75 LB.
STEAM, DTB634
10" (25.4 cm)
14" (35.6 cm)
17" (43.2 cm)
20" (50.8 cm)
22" (55.9 cm)
24" (61.0 cm)
26" (66.0 cm)
28" (71.1 cm)
30" (76.2 cm)
31" (78.0 cm)
33" (83.8 cm)
34" (86.4 cm)
Figure 5
T030IE3B
INSPECTION OR
CLEANOUT COVER
E D C B A
45˚
120 LB. 170 LB.
GAS & STEAM GAS & STEAM
10" (25.4 cm) 12" (30.5 cm)
15" (38.1 cm) 17" (43.2 cm)
18" (45.7 cm) 21" (53.3 cm
21" (53.3 cm) 24" (60.1 cm)
24" (61.0 cm) 27" (68.6 cm)
26" (66.0 cm) 30" (76.2 cm)
28" (71.1 cm) 32" (81.3 cm)
30" (76.2 cm) 34" (86.4 cm)
32" (81.3 cm) 36" (91.4 cm)
33" (83.8 cm) 38" (96.5 cm)
35" (88.9 cm) 40" (101.6 cm)
36" (91.4 cm) 42" (106.7 cm)
WALL
2" (5.1 cm)
MINIMUM
EXHAUST
OUTLET
NO SCREEN
OR CAP
T056IE3B
