17 Technical Information
Profibus Message Mapping
Offset Size Unit
Byte Byte Res
1 2 Hz
3 2 Hz
Tab. 14 Input buffer (15 words)
Offset Size Unit
Byte Byte Res
0 2 mA
2 2 W
4 2 W
6 2 Hz
8 2 Hz
10 2 -
12 2 -
14 2 -
16 2 min
18 2 hours
20 1 V
21 1 °C
352/372
Range Description
475 - High Speed Value
555
Set the high rotational speed, default = 555
475 - Low Speed Value
555
Set the low rotational speed, default = 475
Range Description
0-10000 Current
Motor current consumption
0-500 Power
Motor power absorption
0-400 Power Limit Applied
Maximum allowable power
0-555 Driving Frequency
Read the rotational speed of the pump
0-555 Target Frequency
Read the target rotational speed
- Flow Meter Alarm Time
Specific option, not available on standard models
- Flow Meter Alarm Event
Specific option, not available on standard models
0-65536 Cycle Number
Number of cycles (start and stop) done by the pump
0-65536 Last Cycle Time
How long the last cycle lasted
0-65536 Pump Life
Total pump running time
0-100 Voltage
Voltage provided to the motor
0-70 Pump Bearing Temperature
Read the pump upper bearing temperature.If > 60°C the
controller goes in fail and the pump is stopped
Turbo-V 2K-G Pumping System User Manual / 87-900-968-01 (G)
Win
Serial
120
117
Win
Serial
200
201
155
203
120
213
215
301
300
302
201
204
