EN
spring pre-load adjuster B.
• Lack of grip
Dirt roads or not very challenging roads
To absorb even the smallest roughness,
open (turn towards "-") the compression
adjuster C by a few clicks..
B
Challenging terrain
For the use on challenging terrain it is
necessary to intervene on the extension
adjuster A. To find the right grip balance
of the front wheel with respect to the ter-
rain, open (turn towards "-") or close (turn
towards "+") the adjuster.
Potholes in sequence or strong compres-
sions
In the presence of potholes or strong com-
pressions, close (turn towards "+") the com-
pression adjuster C by a few clicks and,
if necessary, close (turn towards "+") the
spring pre-load adjuster B as well. Balance
out the extension adjuster A accordingly
to keep the best contact with the ground.
Muddy terrain
Act on the spring pre-load adjuster B by
closing it (turning it towards "+") by a few
turns to compensate for the weight of the
mud that adheres to the bike, and to main-
tain a correct and constant setup.

SHOCK ABSORBER

ADJUSTING THE REBOUND
DAMPER
Turn screw A to adjust the hydraulic re-
bound damper.
A
Turning the screw anticlockwise (out) de-
creases the damping effect.
For standard setting, refer to page 11.
