REMOVING THE SEAT INSERT
EN
In order to optimally adapt the car seat to your child's body size, a seat insert
(q) has been provided as standard and is already inserted under the seat
cover.
• We recommend using this seat insert for children aged 9 to 24 months.
• From the age of 25 month, the seat insert is no longer necessary.
• The car seat can then be adjusted to your child's body simply by using the
adjustable headrest (c).
To remove the seat insert:
1. Release the front push buttons of the seat cover from the seat cushion (e).
2. Pull the fabric cover from the cover guides up and forward until you can pull
out the seat insert (q).
3. Restore the seat cover to its original state and fix it in place again.
CORRECT INSTALLATION MODE
Group 1: 9 ‒ 18 kg
Installations-
with impact shield
modus
Installation
9 - 24 M
with seat insert
8
Group 2/3: 15 ‒ 36 kg
without impact shield
> 24 M
without seat insert
SECURING THE CHILD WITH IMPACT SHIELD – GROUP 1 (9–18 KG)
1. Insert the impact shield (f). The side flaps of the impact shield (f) fit exactly
between the arm rests and seating surface of the booster. Push the central
adjustment button (p) and adapt the impact shield to your child.
2. Pull out the entire length of the vehicle seat belt.
3. Place the lap belt over the designated red belt routing on the impact shield (g).
4. Lock the vehicle seat belt into the belt buckle. It must lock in place with an
audible "CLICK".
5. Tighten the lap belt by pulling the shoulder belt backwards.
6. Feed the shoulder belt in parallel with the lap belt back into the belt routing
(g) and pull the shoulder belt tight. Ensure that both parts of the belt cover
the entire width of the impact shield (f) in the belt routing (g).
7. Feed the shoulder belt tightly through the belt routing of the impact shield (g)
until it is clamped inside the belt guide.
8. Put the shoulder belt between headrest (c) and backrest (b). The shoulder
belt does not need to be guided through the shoulder belt guide (i).
SWITCH FROM GROUP 1 TO GROUP 2/3
Remove the impact shield (f), as soon as your child weighs 18 kg.
Switching from group 1 to group 2/3 is not permitted if your child weighs
��
less than 15 kg. Keep the impact shield in a safe and secure place.
SECURING THE CHILD WITHOUT IMPACT SHIELD – GROUP 2/3
(15–36 KG)
1. Route the vehicle seat belt around your child and insert the belt tongue into
the belt buckle. It must lock into place with an audible "CLICK".
2. Place the lap belt in the red coloured lap belt guides (h) of the car seat.
3. Pull the shoulder belt to tighten the lap belt.
4. On the side of the car seat next to the belt buckle, the shoulder belt and the
lap belt must be inserted together in the lap belt guide (h).
5. Feed the shoulder belt through the shoulder belt guide (i) until it is inside
the belt guide.
6. Ensure that the shoulder belt runs across your child's clavicle and does not
touch your child's neck. If necessary, adjust the height of the headrest (c) to
change the position of the belt.
