| 02 12 68 | 00 - 01 | Input Channel BUS Send Switch -8 -17

| 02 12 69 | 00 - 01 | Input Channel BUS Send Switch -8 -18

|——————————+—————————+———————————————————————————————————————————————————|

| 02 12 6A | 00 - 01 | Input Channel BUS Send Switch -9 -17

| 02 12 6B | 00 - 01 | Input Channel BUS Send Switch -9 -18

| 02 12 6C | 00 - 01 | Input Channel BUS Send Switch -10 -17

| 02 12 6D | 00 - 01 | Input Channel BUS Send Switch -10 -18

| 02 12 6E | 00 - 02 | Track Channel FX1 Switch -17

| 02 12 6F | 00 - 02 | Track Channel FX1 Switch -18

| 02 12 70 | 00 - 7F | Track Channel FX1 Level -17

| 02 12 71 | 00 - 7F | Track Channel FX1 Level -18

| 02 12 72 | 01 - 7F | Track Channel FX1 Pan -17

| 02 12 73 | 01 - 7F | Track Channel FX1 Pan -18

| 02 12 74 | 00 - 02 | Track Channel FX2 Switch -17

| 02 12 75 | 00 - 02 | Track Channel FX2 Switch -18

| 02 12 76 | 00 - 7F | Track Channel FX2 Level -17

| 02 12 77 | 00 - 7F | Track Channel FX2 Level -18

| 02 12 78 | 01 - 7F | Track Channel FX2 Pan -17

| 02 12 79 | 01 - 7F | Track Channel FX2 Pan -18

| 02 12 7A | 00 - 02 | Track Channel FX3(AUX1) Switch -17

| 02 12 7B | 00 - 02 | Track Channel FX3(AUX1) Switch -18

| 02 12 7C | 00 - 7F | Track Channel FX3(AUX1) Level -17

| 02 12 7D | 00 - 7F | Track Channel FX3(AUX1) Level -18

| 02 12 7E | 01 - 7F | Track Channel FX3(AUX1) Pan -17

| 02 12 7F | 01 - 7F | Track Channel FX3(AUX1) Pan -18

| 02 13 00 | 00 - 02 | Track Channel FX4(AUX2) Switch -17

| 02 13 01 | 00 - 02 | Track Channel FX4(AUX2) Switch -18

| 02 13 02 | 00 - 7F | Track Channel FX4(AUX2) Level -17

| 02 13 03 | 00 - 7F | Track Channel FX4(AUX2) Level -18

| 02 13 04 | 01 - 7F | Track Channel FX4(AUX2) Pan -17

| 02 13 05 | 01 - 7F | Track Channel FX4(AUX2) Pan -18

| 02 13 06 | 00 - 02 | Track Channel AUX(AUX3) Switch -17

| 02 13 07 | 00 - 02 | Track Channel AUX(AUX3) Switch -18

| 02 13 08 | 00 - 7F | Track Channel AUX(AUX3) Level -17

| 02 13 09 | 00 - 7F | Track Channel AUX(AUX3) Level -18

| 02 13 0A | 01 - 7F | Track Channel AUX(AUX3) Pan -17

| 02 13 0B | 01 - 7F | Track Channel AUX(AUX3) Pan -18

| 02 13 0C | 00 - 01 | Track Channel Solo Switch -17

| 02 13 0D | 00 - 01 | Track Channel Solo Switch -18

| 02 13 0E | 00 - 01 | Track Channel Mute Switch -17

| 02 13 0F | 00 - 01 | Track Channel Mute Switch -18

| 02 13 10 | 00 - 01 | Track Channel Link Switch -17

| 02 13 11 | 00 - 01 | Track Channel Link Switch -18

| 02 13 12 | 00 - 7F | Track Channel Ofset Level -17/18

| 02 13 13 | 00 - 7F | Track Channel Ofset Pan -17/18

| 02 13 14 | 00 - 01 | Stereo In Bus Send Switch -17

| 02 13 15 | 00 - 01 | Stereo In Bus Send Switch -18

| 02 13 16 | 00 - 01 | FX1 Return Bus Send Switch -17

| 02 13 17 | 00 - 01 | FX1 Return Bus Send Switch -18

| 02 13 18 | 00 - 01 | FX2 Return Bus Send Switch -17

| 02 13 19 | 00 - 01 | FX2 Return Bus Send Switch -18

| 02 13 1A | 00 - 01 | FX3 Return Bus Send Switch -17

| 02 13 1B | 00 - 01 | FX3 Return Bus Send Switch -18

| 02 13 1C | 00 - 01 | FX4 Return Bus Send Switch -17

| 02 13 1D | 00 - 01 | FX4 Return Bus Send Switch -18

| 02 13 1E | 00 - 7F | Track Channel Fader Group -17

| 02 13 1F | 00 - 7F | Track Channel Fader Group -18

+————————————————————————————————————————————————————————————————————————+

GLocate Parameter

| Start

address |

Data

|==========+=========+===================================================|

| 03 00 00 | 0aaaaaaa| LOCATE-1

| 03 00 01#| 0bbbbbbb|

| 03 00 02#| 0ccccccc|

| 03 00 03#| 0ddddddd|

| 03 00 04 | 0aaaaaaa| LOCATE-2

| 03 00 05#| 0bbbbbbb|

| 03 00 06#| 0ccccccc|

| 03 00 07#| 0ddddddd|

| 03 00 08 | 0aaaaaaa| LOCATE-3

| 03 00 09#| 0bbbbbbb|

| 03 00 0A#| 0ccccccc|

| 03 00 0B#| 0ddddddd|

| 03 00 0C | 0aaaaaaa| LOCATE-4

| 03 00 0D#| 0bbbbbbb|

| 03 00 0E#| 0ccccccc|

| 03 00 0F#| 0ddddddd|

Off,On |

Off,Pre,Post |

0,,,127 |

L63,,,R63 |

Off,Pre,Post |

0,,,127 |

L63,,,R63 |

Off,Pre,Post |

0,,,127 |

L63,,,R63 |

Off,Pre,Post |

0,,,127 |

L63,,,R63 |

Off,Pre,Post |

0,,,127 |

L63,,,R63 |

Off,On |

0,,,127 |

L63,,,R63 |

Off,On |

0,,,8 = Off,1,,,8|

Contents and remarks

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

| 03 00 10 | 0aaaaaaa| LOCATE-5

| 03 00 11#| 0bbbbbbb|

| 03 00 12#| 0ccccccc|

| 03 00 13#| 0ddddddd|

| 03 00 14 | 0aaaaaaa| LOCATE-6

| 03 00 15#| 0bbbbbbb|

| 03 00 16#| 0ccccccc|

| 03 00 17#| 0ddddddd|

| 03 00 18 | 0aaaaaaa| LOCATE-7

| 03 00 19#| 0bbbbbbb|

| 03 00 1A#| 0ccccccc|

| 03 00 1B#| 0ddddddd|

| 03 00 1C | 0aaaaaaa| LOCATE-8

| 03 00 1D#| 0bbbbbbb|

| 03 00 1E#| 0ccccccc|

| 03 00 1F#| 0ddddddd|

| 03 00 20 | 0aaaaaaa| Loop Start Point

| 03 00 21#| 0bbbbbbb|

| 03 00 22#| 0ccccccc|

| 03 00 23#| 0ddddddd|

| 03 00 24 | 0aaaaaaa| Loop End Point

| 03 00 25#| 0bbbbbbb|

| 03 00 26#| 0ccccccc|

| 03 00 27#| 0ddddddd|

| 03 00 28 | 0aaaaaaa| Punch In Point

| 03 00 29#| 0bbbbbbb|

| 03 00 2A#| 0ccccccc|

| 03 00 2B#| 0ddddddd|

| 03 00 2C | 0aaaaaaa| Punch Out Point

| 03 00 2D#| 0bbbbbbb|

| 03 00 2E#| 0ccccccc|

| 03 00 2F#| 0ddddddd|

| 03 01 00 | 0aaaaaaa| Marker Time or Marker Number

| 03 01 01#| 0bbbbbbb|

| 03 01 02#| 0ccccccc|

| 03 01 03#| 0ddddddd|

| 03 01 04 | 00 - 04 | Marker/Locator Command

(*)

The address marked by "#" are invalid. Transmit the Data Set (DT1) or Data Request

(RQ1) message with the specified size to the address without "#" mark.

(*)

Time parameters are set to the relocated time (REL) that the time of song top is

"00:00:00:00."

(*1)

The VS-1880 treats the 16 samples as 1 block for managing internal time. Pay

attention to the expression of the internal time changes respond to the sampling

frequency of each song. And time parameter can not be set to over 24 hours.

Example 1) Set the time 00:01:00:00 (30 Non-Drop)

Sampling Frequency is 48 kHz :

2880000 sample = 180000 block = 00 0A 7E 20 (7bit Hex)

Sampling Frequency is 44.1 kHz :

2646000 sample = 165375 block = 00 0A 0B 7F (7bit Hex)

Sampling Frequency is 32 kHz :

1920000 sample = 120000 block = 00 07 29 40 (7bit Hex)

Example 2) Set the time 23:59:59:29 (30 Non-Drop)

Sampling Frequency is 48 kHz :

4147198400 sample = 259199900 block = 7B 4C 27 1C (7bit Hex)

Sampling Frequency is 44.1 kHz :

3810238530 sample = 238139908 block = 71 46 74 04 (7bit Hex)

Sampling Frequency is 32 kHz :

2764798933 sample = 172799933 block = 52 32 6F 3D (7bit Hex)

(*2)

The Loop Start point must be before the Loop Stop point. The Auto Punch In point

must be before the Auto Punch Out point. If the interval of each point is shorter than

1 sec, the VS-1880 does not work correctly.

(*3)

Read/Write/Erase of the Mark points are done by writing operation mode to the

Marker command. Set the value of the Marker Time and Marker Number, before

setting the value of the Marker command.

Example 1) Delete all mark points ( DeviceID = 10 )

(HOST)

F0 41 10 00 0E 12 03 01 00 7F 7F 7F 7F 7A F7

(HOST)

F0 41 10 00 0E 12 03 01 04 02 74 F7

(HOST)

F0 41 10 00 0E 12 03 01 00 00 00 00 00 ss F7

Aplicación MIDI

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

or 0,,,999 Marker Number, >=1000 All

00=Marker Read (*3)

01=Marker Write (*3)

02=Marker Clear (*3)

03 = Get Locate Bank (*4)

04 = Set Locate Bank (*4)

(*1) |

(*1,2) |

(*1,3) |

(VS-1880)

105
