ERSATZTEILE / SPARE PARTS / PEÇAS SOBRESSALENTES / PIEZAS DE RECAMBIO /
47.2 Explosionszeichnung / Exploded view / Vista explodida / Vista de despiece /
Vue éclatée / Výkres v rozloženém stavu
Machine body
Transmission assembly
No.
1 Connecting plate
2 Gas spring
3
Screw
4
Guide post
5 Small saw assembly
6
Big saw lift base assembly
7
Small saw assembly
HOLZMANN Maschinen GmbH
Description
www.holzmann-maschinen.at
PIÈCES DE RECHANGE / NÁHRADNÍ DÍLY
No. Description
1 Machine body
2 Right rotation seat
3
Left rotation seat
7
Electrical box
No.
24 Bolt
25 Nut
26
Hexagon half-round head screw
27
Guard
28 Swivel bolt
29
Fixed block
30
Bolt
Description
FKS400V32PRO_400V
