Measurement precision:
Time measurement:
Connections Back panel of the
Data in- and output:
Bath backlighting:
Mains connector:
To be connected to the front panel of ViscoPump III
Pneumatic connectors:
Capacitive sensor:
ViscoPump III module:
Power supply:
Casing:
Dimensions:
Weight:
Ambient conditions:
Climate:
Pollution degree:
Precision (reproducibility and comparability) in accordance with DIN 51562, Part 1
± 0.01 s ± 1 digit, but not more accurate than 0.01 %
measurement incertainty in the determination of absolute, kinematic viscosity furthermore
depends on the incertainty of the numerical value of the viscometer constants and the
/measurement conditions, especially as concerns the measurement temperature.
device:
1serial RS-232-C interface:
for use with a serial data printer
1 device connector, round-plug connector with 7 channel DIN bayonet catch for
connecting an automatic viscometer cleaning unit
Circular connectors with bayonet lock DIN 4 pin, 24 V, 350 mA
Device plug with safety interrupter according to VDE 0625, IEC 320/C14,
EN 60320/C14, DIN 49 457 B
Aerate pressure/suction to be connected to viscometer.
Overflow protection for suction hose VZ 8552
DIN round-plug connector, 4-channel (ViscoPump III module)
Screwed cap according to DIN 45321
DIN round-plug connector with bayonet catch
®
- for AVS /S (measurement stand), 5-channel or
- for TC viscometer, 4-channel
Corresponds to Protection Class 1 according to DIN 57 411, Part 1 / VDE 0411, Part 1
Mains connection:
Mains fuse:
Power consumption:
Steel/aluminium casing with chemically resistant two-component coating, stackable
approx. 255 x 204 x 320 mm (W x H x D)
approx. 5.34 kg with 1 ViscoPump III module
Do not use the device in hazardous locations!
Ambient temperature: + 10 ... + 40 °C for operation and storage
Humidity according to EN 61 010, Part 1:
Max. relative humidity 80 % for temperatures up to 31 °C,
linear decrease down to 50 % relative humidity at a temperature of 40 °C
Pollution degree IP 20, indoor use only.
9-channel sub-miniature D sockets:
modules:
100 - 240 V, 50 ... 60 Hz
Fine-wire fuse 5 x 20 mm, 250 V~, 4 A, time-lag design
100 VA
