5. Description and construction

The main material used in the construction of the hull is moulded fiberglass on the
basis of polyester resin. At equipment fixing points there are located reinforcements and
embedded details. Connection of hull and deck is made with stainless steel fasteners.
Along the perimeter of the board a fender guard is mounted that protects the boat from
damage. The main parts of the boat and equipment layout is shown in Figure 1 (general
arrangement).
In the middle part of the cockpit a control panel is located which includes: a remote con-
trol joystick, a radio with MP3 player, an accumulator battery charge level indicator, indica-
tors of direction, USB and AUX inputs, an emergency power switch and an armrest. Seats,
backrests and armrest have an upholstery. The fore part of the cockpit is equipped with
a niche for the accumulator battery. Seats have soft backrests. The aft deck of the boat
has a compartment with an opening cover (bonnet). In the rear compartment there are
located: a buoyancy block and an underbonnet with a steering unit mounted on it. On the
under-bonnet there are located some elements of the electric system and additional AB.
On the underwater part of the stern there are mounted stationary electric motors with
propeller assembly and motor protection frames. On the deck there are located mooring
cleats, fittings of awning fastenings and cup holders. The fore and stern of the boat are
provided with fixing brackets. At the top of the bow a towing shackle is mounted.

5.1 Buoyancy block

Emergency buoyancy is achieved by placing expanded polystyrene blocks in the cavity
between the upper and lower parts of the shell. Buoyancy blocks are located in the stern
and bow parts of the boat.

5.2 Drainage channels

The boat is equipped with a system of scuppers, draining the water into the intrahull
space. The water should be drained from the intrahull space on the bank through the
transom plug located in the lowest part of the transom.
Warning!
Boat launching with an open transom plug is prohibited!
We recommend leaving the transom plug open when the boat is on the shore to drain
the rain waters from the cockpit and dry the intrahull space.
Warning!
Before launching the boat, make sure the transom cap is in place and screwed
down tightly.

5.3 AB charge level indicator

At the top of the console there is a LED indicator that indicates the charge level of the
battery.
