Item Part No. Qty.
1004981
1
2 3007549
3 3007550
4 3007551
5 3007552
6 3007661
7 557620
8 3006615
9 3006840
10 3007315
11 3007316
12 3007548
13 400182
14 400408
15 444758
16 446136
17 446154
18 452006
19 453017
20 366883
21 402056
22 444306
23 5003217
24 3008195
25 3009210
26 403741
27 446110
28 1005002
Description
1 Hood Assembly
1 • Foam, Front
1 • Foam, Right Side
1 • Foam, Left Side
1 • Foam, Top
1 • Seal, Rear
AR • Molding
1 Shell, Bumper
1 Bracket, Hood Hinge
1 Seal, Left Side Air
1 Seal, Right Side Air
1 Foam, Control Module
6 Screw, 5/16-18 x 5/8" Hex Head
4 Screw, 1/2-13 x 1-1/2" Hex Head
2 Locknut, 1/2-13 Center
6 Lockwasher, 5/16 Heavy
2 Lockwasher, 1/2 Heavy
6 Flat Washer, 5/16
6 Flat Washer, 1/2
1 Over Center Latch
2 Screw, #8-32 x 3/8" Slotted Head
4 Nut, #8-32 Hex
1 Cover, Front Mount
1 Wing Nut, 1/4-20 Steel
1 Foam (Cut To Length)
2 Screw, #8-32 x 5/8" Hex Head
4 Lockwasher, #8
1 Bumper, Weight
Serial Numbers/Notes
Includes Items 16 ~ 20 on Illustration 1.1
2WD Units Only
> Change from previous revision
