Item Part No. Qty.
3006981
1
2 1003638
3 360111
4 361648
5 361647
6 471214
7 461393
8 117139
9 363562
10 340491
557621
11 443840
12 452022
13 366789
14 460064
15 460026
16 153234
400194
444718
471214
17 445666
18 1002032
19 1002031
471214
20 445647
21 443120
22 445664
23 3009378
24 471227
25 460050
26 445710
27 1004855
28 1004856
29 5002910
30 554329
31 500596
32 545692
33 354807
34 443110
35 3010781
36 400284
37 452008
38 446142
Description
2 Tire
2 Rim
2 Inflation Valve
6 Washer, Thrust
2 Bearing, Thrust
2 Fitting, Grease
2 Pin, Spring 1/4 x 2"
1 Steering Axle
4 • Bushing
1 Cylinder, Steering
1 • Seal Kit
2 Nut, 1-12 Hex Jam
1 Flat Washer, 1
1 Spacer, Axle
1 Cotter Pin, 1/4 x 1-1/2"
4 Cotter Pin, 1/8 x 3/4"
2 Ball Joint
2 • Screw, 5/16-18 x 1-3/4"
2 • Locknut, 5/16-18 Hex
2 • Grease Fitting
2 • Nut, 1/2-20 Slotted Hex
1 Ball Joint, Right Hand
1 Ball Joint, Left Hand
2 • Grease Fitting
2 • Nut, 3/8-24 Slotted Hex
1 Nut, 1/2-20 Hex
1 Nut, 1/2-20 Hex Left Hand Thread
1 Tie Rod
1 45° Grease Fitting
2 Cotter Pin, 3/16 x 1-1/4"
2 Nut, 1-14 Slotted Hex
1 Spindle, Right
1 Spindle, Left
2 Wheel Hub
2 • Seal, Grease
2 • Bearing, Cup and Cone
2 • Dust Cap
8 • Wheel Nut
4 Nut, 3/8-16 Hex
3 Weight, Rear
4 Screw, 3/8-16 x 5" Hex Hd
8 Washer, 3/8 Flat
4 Lockwasher, 3/8 Hvy
HR-4600
Serial Numbers/Notes
> Change from previous revision
43
