13.1 Engine Exhaust

Item Part No.
1002931
1
2 1004598
3 363586
4 452006
5 363485
6 362263
7 446136
8 553020
9 348856
10 3007889
52
3
7
4
7
3
Qty. Description
1 Muffler
1 Tailpipe
6 Screw, M8-1.25 x 20mm Hex Head
2 Flat Washer, 5/16
2 Lockwasher, M10 Heavy
2 Bolt, M10-1.25 x 25mm Hex Head
6 Lockwasher, 5/16 Heavy
1 Gasket, Exhaust
1 Clamp, Exhaust
1 Sleeve Insulating
1
8
9
10
2
5
6
Serial Numbers/Notes
> Change from previous revision
Serial No. All
