Item Part No. Qty.
366292
1
2 5002909
3 360111
4 1001757
5 554780
6 554779
7 5003161
8 345666
9 1002862
10 400188
11 –
12 –
13 2000141
14 3007862
15 340486
16 446154
17 400410
18 353914
19 400108
20 400612
21 446166
22 443126
23 453020
24 460093
25 1003047
26 557771
27 461493
28 460014
Description
2 Tire
2 Rim
2 Valve, Inflation
2 Motor, Wheel
2 • Key
2 • Nut, Hex
1 Frame
2 Clamp
1 Axle, Front
2 Screw, 5/16-18 x 1" Hex Hd
1 Brake Assembly
1 Brake Assembly
2 Hub, Wheel
2 Spring, Extension
2 Brake, Disk
8 Lockwasher, 1/2 Heavy
8 Screw, 1/2-13 x 1-3/4" Hex Head
12 Bolt, Wheel
16 Screw, 1/4-20 x 3/4" Hex Head
4 Screw, 5/8-11 x 1-1/2" Hex Head
4 Lockwasher, 5/8 Heavy
4 Nut, 5/8-11 Hex
4 Washer, 5/8 Flat
2 Pin, 1/8 x 2-1/2" Cotter
2 Cable, Brake
2 • Clip, Brake Cable
2 Pin, 5/16 x 3/4" Clevis
2 Pin, 3/32 x 3/4" Cotter
Serial Numbers/Notes
See Illustration 35.1
See Illustration 33.1
See Illustration 33.1
> Change from previous revision
HR-4600
41
