| 02 06 00 | 00 - 01 | FX1 Master Insert Sw

| 02 06 01 | 00 - 7F | FX1 Master Send Level

| 02 06 02 | 00 - 7F | FX1 Master Return Level

| 02 06 03 | 00 - 01 | FX2 Master Insert Sw

| 02 06 04 | 00 - 7F | FX2 Master Send Level

| 02 06 05 | 00 - 7F | FX2 Master Return Level

| 02 06 06 | 00 - 7F | Master Out Level

| 02 06 07 | 01 - 7F | Master Out Balance

| 02 06 08 | 00 - 7F | Master AUX Send Level

| 02 06 09 | 01 - 7F | Master AUX Send Balance

| 02 06 0A | 00 - 7F | Master FX1 Send Level

| 02 06 0B | 01 - 7F | Master FX1 Send Balance

| 02 06 0C | 00 - 7F | Master FX2 Send Level

| 02 06 0D | 01 - 7F | Master FX2 Send Balance

| 02 06 0E | 00 -

| (Reserved)

| 02 06 0F | 00 - 04 | Master Select

| 02 06 10 | 00 - 02 | AUX Output Select

| 02 06 11 | 00 - 03 | Digital 1 Output Select

| 02 06 12 | 00 - 03 | Digital 2 Output Select

| 02 06 13 | 00 - 02 | Direct Output Switch

| 02 06 14 | 00 - 01 | EQ Mode

+——————————+—————————+———————————————————————————————————————————————————+

GParámetros de localización

+————————————————————————————————————————————————————————————————————————+

| Start

address |

Data

|==========+=========+===================================================|

| 03 00 00 | 0aaaaaaa| LOCATE-1

| 03 00 01#| 0bbbbbbb|

| 03 00 02#| 0ccccccc|

| 03 00 03#| 0ddddddd|

| 03 00 04 | 0aaaaaaa| LOCATE-2

| 03 00 05#| 0bbbbbbb|

| 03 00 06#| 0ccccccc|

| 03 00 07#| 0ddddddd|

| 03 00 08 | 0aaaaaaa| LOCATE-3

| 03 00 09#| 0bbbbbbb|

| 03 00 0A#| 0ccccccc|

| 03 00 0B#| 0ddddddd|

| 03 00 0C | 0aaaaaaa| LOCATE-4

| 03 00 0D#| 0bbbbbbb|

| 03 00 0E#| 0ccccccc|

| 03 00 0F#| 0ddddddd|

| 03 00 10 | 0aaaaaaa| LOCATE-5

| 03 00 11#| 0bbbbbbb|

| 03 00 12#| 0ccccccc|

| 03 00 13#| 0ddddddd|

| 03 00 14 | 0aaaaaaa| LOCATE-6

| 03 00 15#| 0bbbbbbb|

| 03 00 16#| 0ccccccc|

| 03 00 17#| 0ddddddd|

| 03 00 18 | 0aaaaaaa| LOCATE-7

| 03 00 19#| 0bbbbbbb|

| 03 00 1A#| 0ccccccc|

| 03 00 1B#| 0ddddddd|

| 03 00 1C | 0aaaaaaa| LOCATE-8

| 03 00 1D#| 0bbbbbbb|

| 03 00 1E#| 0ccccccc|

| 03 00 1F#| 0ddddddd|

| 03 00 20 | 0aaaaaaa| Loop Start Point

| 03 00 21#| 0bbbbbbb|

| 03 00 22#| 0ccccccc|

| 03 00 23#| 0ddddddd|

| 03 00 24 | 0aaaaaaa| Loop End Point

| 03 00 25#| 0bbbbbbb|

| 03 00 26#| 0ccccccc|

| 03 00 27#| 0ddddddd|

| 03 00 28 | 0aaaaaaa| Punch In Point

| 03 00 29#| 0bbbbbbb|

| 03 00 2A#| 0ccccccc|

| 03 00 2B#| 0ddddddd|

| 03 00 2C | 0aaaaaaa| Punch Out Point

| 03 00 2D#| 0bbbbbbb|

| 03 00 2E#| 0ccccccc|

| 03 00 2F#| 0ddddddd|

Off,Ins |

0,,,127 |

Off,Ins |

0,,,127 |

L63,,,R63 |

0,,,127 |

L63,,,R63 |

0,,,127 |

L63,,,R63 |

0,,,127 |

L63,,,R63 |

MIX, AUX, FX1, FX2, REC |

AUX, FX1,FX2, |

Master, AUX, FX1, FX2 |

or 1-2, 3-4, 5-6, 7-8 |

Master, AUX, FX1, FX2 |

or 1-2, 3-4, 5-6, 7-8 |

Off, 1-4, 5-8 |

2Band,3Band |

Contents and remarks

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1,2) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1,2) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1,2) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

(*1,2) |

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

| 03 01 00 | 0aaaaaaa| Marker Time or Marker Number

| 03 01 01#| 0bbbbbbb|

| 03 01 02#| 0ccccccc|

| 03 01 03#| 0ddddddd|

| 03 01 04 | 00 - 04 | Marker/Locator Command

| 03 01 05 | 00 - 01 | Marker Category

(*)

The address marked by "#" are invalid. Transmit the Data Set(DT1) or Data Request

(RQ1) message with the specified size to the address without "#" mark.

(*)

Time parameters are set to the relocated time(REL) that the time of song top is

"00:00:00:00."

(*1)

The VS-890 treats the 16 samples as 1 block for managing internal time. Pay attention

to the expression of the internal time changes respond to the sampling frequency of

each song. And time parameter cannot be set to over 24 hours.

Example 1) Set the time 00:01:00:00 (30 Non-Drop)

Sampling Frequency is 48 kHz :

2880000 sample = 180000 block = 00 0A 7E 20 (7bit Hex)

Sampling Frequency is 44.1 kHz :

2646000 sample = 165375 block = 00 0A 0B 7F (7bit Hex)

Sampling Frequency is 32 kHz :

1920000 sample = 120000 block = 00 07 29 40 (7bit Hex)

Example 2) Set the time 23:59:59:29 (30 Non-Drop)

Sampling Frequency is 48 kHz :

4147198400 sample = 259199900 block = 7B 4C 27 1C (7bit Hex)

Sampling Frequency is 44.1 kHz :

3810238530 sample = 238139908 block = 71 46 74 04 (7bit Hex)

Sampling Frequency is 32 kHz :

2764798933 sample = 172799933 block = 52 32 6F 3D (7bit Hex)

(*2)

The Loop Start point must be before the Loop Stop point. The Auto Punch In point

must be before the Auto Punch Out point. If the interval of each point is shorter than

1 sec, the VS-890 does not work correctly.

(*3)

Read/Write/Erase of the Mark points are done by writing operation mode to the

Marker command. Set the value of the Marker Time and Marker Number, before

setting the value of the Marker command.

Example 1) Delete all mark points ( DeviceID = 10 )

(HOST) => F0 41 10 00 14 12 03 01 00 7F 7F 7F 7F 7A F7 => (VS-890)

(HOST) => F0 41 10 00 14 12 03 01 04 02 74 F7

(HOST) <= F0 41 10 00 14 12 03 01 00 00 00 00 00 ss F7 <= (VS-890)

The return value "00000000" is a sum of mark points.

Example 2) Write the mark point ( DeviceID = 10 )

(HOST) => F0 41 10 00 14 12 03 01 00 aa aa aa aa ss F7 => (VS-890)

aaaaaaaa = time of Marker

(HOST) => F0 41 10 00 14 12 03 01 04 01 75 F7

(HOST) <= F0 41 10 00 14 12 03 01 00 nn nn nn nn ss F7 <= (VS-890)

nnnn = total marker number, ss = check sum

If the total of mark point is over 1000, the VS-890 ignores the

writing and returns the total numbers of the mark points.

If the mark point already exists 0.1 msec near the new mark point, the

VS-890 ignores the writing and returns the total numbers of the mark

points.

Example 3) Read the mark point #3 ( DeviceID = 10 )

(HOST) => F0 41 10 00 14 12 03 01 00 00 00 00 03 75 F7 => (VS-890)

(HOST) => F0 41 10 00 14 12 03 01 04 00 76 F7

(HOST) <= F0 41 10 00 14 12 03 01 00 nn nn nn nn ss F7 <= (VS-890)

nnnnnnnn = total marker number, ss = check sum

(HOST) <= F0 41 10 00 14 12 03 01 00 aa aa aa aa ss F7 <= (VS-890)

aaaaaaaa = time of Marker #3

Implementación MIDI

aaaaaaabbbbbbbcccccccddddddd =

0,,,268435455block (1block=16sample) |

or 0,,,999 Marker Number, >=1000 All

00=Marker Read (*3)

01=Marker Write (*3)

02=Marker Clear (*3)

03 = Get Locate Bank (*4)

04 = Set Locate Bank (*4)

00=Normal

01=Automix Snapshot

02=Automix Realtime

03=CD-R Index

=> (VS-890)

(*1,3) |
