Product Description - Ottobock 17PA1-20-WR Instrucciones De Uso

1 Foreword
INFORMATION
Date of the last update: 2015-08-26
► Please read this document carefully.
► Follow the safety instructions.
These Instructions for Use provide you with important information on the
installation and processing of the 17PA1=20 - WR Waterproof System Ankle
Joints made of plastic material.

2 Product Description

2.1 Components/Design
Item
1 M6x14 set screw
2 5x20 cylinder pin
3 Countersunk head screw
4 Joint bolt
5 Bearing bushing
6 System ankle joint
7 Foot stirrup (not included in the scope of
delivery!)
8 Joint nut with M6 internal thread
9 M4x12 set screw
10 Receiver for set screw - to secure the bar
11 System bar receiver
12 Ball
13 2.5M6x18 cylinder pin
14 Compression spring
15 M6x35 cap screw
16 Parallel truing tube
17 System bar (not included in the scope of
delivery!)
We reserve the right to make technical changes.
2.2 Function
The waterproof system joints serve as components for waterproof walking
devices and enable walking and standing in wet areas.
Component Article no.
Single components
506G21=M6x14
506A27=5M6x20
17PF1
506G21=M4x12
509Y1=5.0
506A5=2.5M6x18
513D18=4.7x31-2
English
Sets
29PA1
29PA1
29PA1
29PA1
29PK4
29PK4
Ottobock | 9
