ENGLISH
5. Press the Menu/Back
screen.
Note 1: Once the alert is running, an alarm clock icon
(k) will be displayed on the LCD screen.
Note 2: If you want to remove the alarm follow the
steps 1 to 3 mentioned above and set the time to
00:00. The clock icon will disappear.
Note: When the alert is ringing, press any key to
cancel it. If there is no answer, the ringing will last 7
minutes and then stop.
5.2.7.6. VIBRATION FUNCTION
This function allows parents to achieve a silent
environment when they need peace and quiet and it is
a great help in noisy environments and for people who
have hearing problems.
When the sound in the baby's room exceeds the
threshold marked by the sensitivity level configured,
the monitor will vibrate on four occasions to warn the
parents.
To activate the vibration function, follow the next
steps:
1. Press for 3 seconds the Menu/Back
menu will pop up;
key or DOWN
2. Press the UP
vibration setting menu icon
key.
press the
key or DOWN
3. Using the UP
OFF if you want to activate or deactivate this feature.
4. Confirm the selection pressing the
5. Press the Menu/Back
screen.
Bear in mind that the vibration function will only be
configured for the camera whose image you are
viewing on the monitor at that time.
NOTE: In order for the monitor to vibrate when
the volume in the baby's room exceeds a certain
threshold, it is vital for the VOX mode to be active.
5.2.7.7. LUMINOSITY
To modify the luminosity of your monitor, follow the
next steps:
1. Press for 3 seconds the Menu/Back
menu will pop up.
key or DOWN
2. Press the UP
luminosity setting menu icon
key.
press the
key or DOWN
3. Using the UP
luminosity level you prefer from amongst the five
available.
4. Confirm the selection pressing the
5. Press the Menu/Back
screen.
5.2.8. eMyBaby
5.2.8.1. REGISTRATION
1. First of all register on the eMyBaby website. To do
so, open your browser, go to www.emybaby.com
and click on the CREATE ACCOUNT tab.
2. Complete the fields with your personal data and
after having accepted the terms and conditions of use,
click on the ACTIVATE ACCOUNT tab.
key to return to the main
key and the
key until the
is highlighted. Then
key, select ON/
key.
key to return to the main
key and the
key until the
is highlighted. Then
key, choose the
key.
key to return to the main
3. You will receive a message of confirmation at
the e-mail address you provided in the registration
process. Clicking on the link containing the e-mail
message will take you back to the eMyBaby page,
where you need to enter your username and
password after clicking on the SIGN IN tab.
5.2.8.2. IN ORDER TO VIEW THE IMAGE ON THE
PC TO WHICH THE BABY MONITOR
IS CONNECTED
1. In order to view the image from the camera on your
computer you first need to make a few adjustments
to the monitor.
a. Go to the main menu and click on the adjustments
icon.
b. Click on monitor adjustments. Click on "USB
Output" from the options displayed on the list.
c. Once you are in, select the icon from the three
options available.
In this manner, when you connect the monitor to the
computer, you will no longer see the monitor image
and you will be able to see your baby on the computer.
2. In order to see the image transmitted by the camera
on your PC, you should connect the monitor (screen)
to the USB port on your computer using a mini USB-
USB cable (not included). The monitor should be
switched on; if the battery is flat, recharge it.
3. After accessing eMyBaby using your username
and password, select the BABY MONITOR option in
DASHBOARD.
4. Now select the digimonitor 3.5" plus model.
5. There are two options to choose from. Choose
"USB Camera computer connected".
6. If everything is working correctly you should
automatically see your baby on the computer screen.
If there is a problem with the image, consult the
online viewing instructions by clicking on the READ
INSTRUCTIONS icon.
5.2.8.3. IN ORDER TO VIEW THE IMAGE AT A
DISTANCE BY MEANS OF eMyBaby
Follow the instructions below if you wish to view your
baby at a distance on your PC, tablet or Smartphone.
Note: the monitor should be connected to your PC
in order to see the image captured by the camera
at a distance on eMyBaby. eMyBaby must transmit
a signal via the PC to which your baby monitor
screen is connected. If you do not follow this step
you will not be able to receive a signal on any
other appliance (PC, tablet or mobile device).
1. Connect the baby monitor to your PC in accordance
with the aforementioned steps, connecting the monitor
to the USB port on your computer using a mini USB-
USB cable (not included).
2. Access
the
eMyBaby
website using your username and password (register
as instructed above if you do not possess a username
and password) and select the BABY MONITOR
option.
3. Select digimonitor 3.5" plus from the different
models of baby monitor.
4. There are two options to choose from. Choose
"View from anywhere through another computer,
tablet or smartphone".
25
(www.emybaby.com)
