If multiple simultaneous supply injections
are desired, follow this procedure:
• After the Supply key has been pressed,
press any combination of keys 1–5 (up
to 5 individual digits per step) before
pressing the Enter key.
• The computer will add those numbers
to the supply step. All desired supplies
will be turned on for the amount of
time programmed.
The display will show either a letter or
number code to indicate the supply
combination selected. For example,
assume the computer is in the program
mode and the Supply key has been
pressed. The keys 1, 2, and 5 will be
pressed one at a time. After the last key is
pressed, the display will read "SN" as the
first two digits of the display, followed by
the step number, which is then followed by
the cycle number being programmed.
Press the Enter key. The display will read
"M---S." Now assign the desired time in
minutes and seconds for the supply
injection to last.
3. Press the Enter key and go to the next step
in the cycle.
F232090
Programming
SUPPLY DISPLAY CODES
SUPPLY NUMBER
0 = Supply Off
CODE
X = Supply On
1
2
A
3
B
C
D
4
E
F
H
I
J
L
M
5
6
7
N
8
O
P
Q
9
R
S
T
U
V
W
X
5 4 3 2 1
0 0 0 0 X
0 0 0 X 0
0 0 0 X X
0 0 X 0 0
0 0 X 0 X
0 0 X X 0
0 0 X X X
0 X 0 0 0
0 X 0 0 X
0 X 0 X 0
0 X 0 X X
0 X X 0 0
0 X X 0 X
0 X X X 0
0 X X X X
X 0 0 0 0
X 0 0 0 X
X 0 0 X 0
X 0 0 X X
X 0 X 0 0
X 0 X 0 X
X 0 X X 0
X 0 X X X
X X 0 0 0
X X 0 0 X
X X 0 X 0
X X 0 X X
X X X 0 0
X X X 0 X
X X X X 0
X X X X X
41
