Technical Data - Porsche Mobile Charger Connect Manual De Instalación

Technical Data

Technical Data
DE
EN
Electrical data 9Y0.971.675...
Power
FR
Rated current
IT
Mains voltage
ES
Phases
PT
Mains frequency
NL
Overvoltage category (IEC 60664)
Integrated residual current device
SV
Protection class
FI
Protection rating
DA
Transmission frequency bands
Transmission power
NO
Mechanical data
EL
Weight of control unit
CZ
Length of vehicle cable
Length of supply cable
HU
Mechanical data for basic wall mount
PL
Basic wall mount dimensions
HR
Weight of basic wall mount
Cable guide dimensions
SR
Weight of cable guide
SK
Connector fastener dimensions
Weight of connector fastener
SL
Weight of complete basic wall mount
ET
Mechanical data for charging dock
LT
Charging dock dimensions
Weight of charging dock
LV
Ambient and storage conditions
RO
Ambient temperature
BG
Humidity
Altitude
MK
18
BE BG
7.2 kW 11 kW
16 A 2-phase 16 A 3-phase
32 A 1-phase
100 – 240 V/400 V 100 – 240 V/400 V
2/1 3
50 Hz/60 Hz 50 Hz/60 Hz
II II
Type A (AC: 30 mA) + DC: 6 mA Type A (AC: 30 mA) + DC: 6 mA
I I
IP55 (USA: Enclosure 3R) IP55 (USA: Enclosure 3R)
2.4 GHz, 5 GHz 2.4 GHz, 5 GHz
20 dBm 20 dBm
2.54 kg
2.5 m or 7.5 m
0.9 m
385 mm x 135 mm x 65 mm (length x width x height)
approx. 0.45 kg
127 mm x 115 mm x 139 mm (length x width x height)
approx. 0.42 kg
136 mm x 50 mm x 173 mm (length x width x height)
approx. 0.14 kg
approx. 1 kg
373 mm x 642 mm x 232 mm (width x height x depth)
approx. 9.7 kg
–30 °C to +50 °C
5% – 95% non-condensing
max. 5,000 m above sea level
BJ
22 kW
32 A 3-phase
100 – 240 V/400 V
3
50 Hz/60 Hz
II
Type A (AC: 30 mA) + DC: 6 mA
I
IP55 (USA: Enclosure 3R)
2.4 GHz, 5 GHz
20 dBm
