Reversing Door Procedure . . .

The door on this dryer is completely reversible. To reverse door proceed as follows:
1
Remove four
hinge attaching
screws.
3
Pull bottom of
door liner out,
then pull down,
removing door
B
liner from door
panel.
A
5
Remove door strike
from door liner
and reinstall on
opposite side.
7
Reinstall nine screws
removed in Step 2.
10
D271PE1B
D268PE1A
D276PE1B
D270PE1B
9
Reinstall four hinge
attaching screws
removed in Step 1.
2
Remove all nine screws.
4
Rotate door panel
180 degrees
as shown.
6
Insert liner under
flange on bottom of
B
door, then push
top of door
liner into place. A
8
Using a screwdriver,
remove two door plugs,
and reinstall on
opposite side of
door opening.
D275PE1A
D272PE1A
D273PE1C
D269PE1C
D274PE1A
