SmartLite®Pro
Modular LED Curing Light
CAUTION: For dental use only.
USA RX Only.
CONTENT
1. PRODUCT DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. SAFETY NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3. STEP-BY-STEP INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4. HYGIENE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
5. MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

1. PRODUCT DESCRIPTION

The SmartLite Pro curing light is a cordless pen-style, LED light polymerization and
illumination device for use by dental professionals in dental offices or dental laboratories.
SmartLite Pro curing light is characterized by:
• Small size and lightweight ergonomic design .
• Compact cordless design with convenient handling features and exchangeable battery pack .
• Individually adjustable LED tips, rotatable by 360° .
• LED tip design providing excellent intra-oral access .
• Polymerization area (optic effective cross-sectional area) of 10 mm in diameter .
• Up to 10 seconds curing time per activation with audible signal at start and end of cycle .
• Advanced heat management system limiting LED tip temperature .
• Exchangeable tips for:
- curing of CQ initiated materials
- curing of materials with initiators absorbing in the violet range
- intraoral illumination and dental transillumination
1.1 Indications
• For light activated polymerization of dental materials such as composites, luting cements,
and sealants using visible light .
• For Intraoral illumination used upon initial examination of the dental patient and dental
transillumination to help locate crown fractures, posterior and anterior caries, endodontic
access and root canal orifices .
1.2 Contraindications
The Smartlite Pro curing light is contraindicated for use in patients prone to photobiological
reactions (including patients with solar urticaria or erythropoietic protoporphyria) or those
currently undergoing treatment with photosensitizing pharmaceuticals .
1.3 Delivery Forms
Some delivery forms may not be available in all countries .
PRODUCT CONTENTS LIST (Note: See catalogue for detailed Intro Kit contents)
• 1x Handpiece
1
• 1x Cure Tip (blue light)
2
• 1x Transillumination Tip (only in Introductory Kit)
• 2x Batteries
3.1
5
• 1x Charging Base
6
4
• 1x Accessories Box containing:
Power Connector; AU, EU, US, UK Plug Adapters; Power Cord (USB)
1x DFU
1x SmartLite Pro Sleeves refill
3x SmartLite Pro Shields
1x i•Cure
• 1x Curing Guidelines/Material Curing Card
1.4 Compatible Materials
SmartLite Pro curing light is designed to cure conventional CQ-initiated 450-480nm
wavelength dental polymer- based restorative and luting materials with the standard Cure
tip . The PolyCure tip is designed to cure materials initiated with CQ and/or other initiators
absorbing violet light, 405-480nm wavelength . See polymer-based restorative material
manufacturer's complete directions for use for specific product compatibility and curing
recommendations .

2. SAFETY NOTES

Be aware of the following general safety notes and the special safety notes in other chapters
of these Instructions for Use .
Safety alert symbol.
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety messages that follow this symbol to avoid possible injury.
2.1 Warnings
Never modify the SmartLite Pro curing light or any of its equipment . Any modification may
compromise safety and effectiveness .
2.1.1 SmartLite Pro handpiece
• Always make sure the SmartLite Pro eye protection shields are securely fixed to SmartLite
Pro curing tip to avoid accidental aspiration (press the SmartLite Pro eye protection shield
firmly into correct position)
E2
• Always make sure light aperture is not covered by the SmartLite Pro eye protection shields
E3
• Do not use the device as a tissue retractor, as this may damage the connection between
LED tip and handpiece .
• Do not use a damaged device, e . g . if among other things, the glass cover of the LED tip is
scratched, broken or missing .
• The SmartLite Pro eye protection shields will wear over time . Exchange defect shield against
spare shields included in the package or available as refill (see also [6 . 1 Accessories]) .
• Only authorized technicians should repair the handpiece or battery pack .
2.1.2 Charging base
5
• Low voltages are present inside the charging base (5 V DC) . Use only under dry conditions .
Do not use if the charging base or handpiece is wet . Avoid short circuit between contact
pads on the charging base . Only authorized technicians should repair the charging base .
• Do not use for voltages different from the range indicated on the charging base and power
adapter .
7
• Note: Unplug power connector
from power source before disconnecting power cord
from the charging base .
A2
• Always make sure the charging base is placed offside the dental unit and only touched with
clean/disinfected gloves to prevent from exposure to spatter or spray of body fluids
• Always make sure handpiece, tips, and battery pack is completely reprocessed and
thoroughly dry before inserting it into the charging base or attaching a light tip to the body .
2.1.3 Battery pack
3.1
• Prevent battery from short circuit during use and storage .
• Keep electrical contacts clean and dry .
• Do not remove battery pack from hand piece during operation .
8
7
