Register fixed individual code:
1.Press the self-instruction button for at least 0.3 sec, at most 4 sec.
2.Release the button (less than 1 sec).
3.Press the button again (longer than 1 sec).
-Private program mode, the red LED goes out and comes on again.
4.Press the required function button.
-The red LED flashes three times quickly.
5.The private code is now stored.
-The red LED double flashes every other sec.
CO-PROGRAMMING THE TRANSMITTER AND DIN-RE-
CEIVER
T60TX-15SML AND T60RX-03ADL
1. Check that the transmitter's system switch (A) is in the ON position.
2. Set your own code on the transmitter's code switch (B) 1-10.
3.Press the self-instruction button (C) on the receiver.
-The red LED comes on (programming mode 6 sec).
4.If buttons 1-3 are pressed, the relays in the receiver will function as but-
tons 1-3. If buttons 4-6 are pressed, the relays will function as buttons
4-6 etc.
5. Press the required function button (1-15) on the transmitter.
- The red LED flashes three times.
6. Check that the relay is actuated when the same function button is
pressed again.
(A)
1 2 3
+
ON
0
1
T60TX-15DML AND T60RX-03ADL
1.Check that the transmitter's system switch (A) is in the ON
position.
2.Set your own code on the transmitter's code switch (B)
1-10.
3. Press the self-instruction button (C) on the receiver.
-The red LED comes on (programming mode 6 sec).
170
(B)
4 5 6 7 8 9 1 0
(C)
