2.2.1 Machine movement
i
Operation has to be carried out
when the machine is off and cold.
Before handling:
■ Disconnect the power supply cable.
■ Disconnect the water supply.
Once the Machine is placed in the new instal-
lation area, reconnect the power supply cable
and the water pipe. (see chap. 4.2 and 4.4) .
The handling means used must be in per-
fect working conditions.
■ 1 unit - 8,3 litres 1700/2000 W
(plate data 1850/2300 W)
■ 2 units - 13,2 litres 3000/4000/5000 W
(plate data 3300/4300/5300 W)
■ 3 units - 23 litres 4000/5000 W
(plate data 4300/5300 W)
installed
MACHINE
UNDER
MAINTENANCE
BOXER
3
- DESCRIPTION OF THE
MACHINE
3.1 Designated use
The machines have been designed and man-
ufactured to be used to make espresso coffee
and hot beverages (tea, cappuccino, etc.).
Any other use is to be considered unsuitable
and therefore dangerous.
The manufacturer cannot be
i
held responsible for any damage
caused to people or things due to
unsuitable, erroneous or irration-
al use of the machine
The operator must always follow the indica-
tions contained in this manual. In the case
of a failure or if the machine is not working
properly, switch it off and do not attempt any
direct repair. Contact the service center.
3.2 Technical specifications
■ Display timer.
■ Service boiler capacity:
1 unit - 8,3 litres 1700/2000 W
(plate data 1850/2300 W)
2 units - 13,2 litres 3000/4000/5000 W
(plate data 3300/4300/5300 W)
3 units - 23 litres 4000/5000 W
(plate data 4300/5300 W)
■ Voltage: 220-240/380-415V 3N
■ Permanent magnets volumetric pump
■ Frequency:
50/60Hz. for CE versions
220 V / 60 Hz. for USA/CAN versions
■ Dimensions and weight (fig_3.1)
1 unit = 480 x 471 x 490 mm
2 units = 630 x 471 x 490 mm
3 units = 850 x 471 x 490 mm
(Width A x height B x depth C)
1 unit
2 units
3 units
EN
49 kg
62 kg
71 kg
