Vertical system setup

Adjust the ground level position
The signal ground level is identified by the position of the
Ground level
indicator
Move both
– pressing
– pressing
Moving the waveform to the top offsets the waveform with a negative voltage
value, while moving to the bottom offsets it with a positive voltage value.
Keysight U1610/20A User's Guide
and the waveform vertically by:
, or
and using the
Using the Oscilloscope
icon on the display.
or key.
3
