Voltage Measurements

Ensure that the probe tips are in contact with the metal contacts inside the
WARNING
outlet. Improper contact may lead to inaccurate voltage measurement. Poor
contact will cause inaccurate readings and poses a risk of electrocution.
Voltage measurements consist of:
– V AC – Measurements are returned as true RMS readings, which are accurate
– V DC – Measurements are returned with their polarity.
– V AC+DC – Both AC and DC signal components are measured as one AC+DC
To measure voltage:
1 Press
Keysight U1610/20A User's Guide
for sine waves and other waveforms (with no DC offset).
(RMS) value combined.
and use the
function. Set up the following connections:
Using the Digital Multimeter
keys to select the voltage measurement
DC
