1 GENERAL

This documentation supplies the general indications for the storage, installation and use of the E.box electric panel,
which has been designed and made for the control and protection of Sets of 1 or 2 pumps for: drainage (emptying),
filling and pressure boosting.
WHERE TO INSTALL THE PANEL:
It is good practice to install the panel correctly, taking particular care to comply with the following indications.

the panel must be kept in a completely dry place, far from sources of heat;

the electric panel must be perfectly closed and isolated from the outside environment, so as to avoid the entry of
insects, humidity and dust which could damage the electrical components, jeopardising their regular operation.

Choose the sensors with a grade of protection suitable for the place in which they will be positioned.

1.1 Technical characteristics

Power supply
+10% - 15%
Frequency
Grade of protection
No. pumps that can be connected:
Maximum rated current of the pumps
Maximum rated power of the pumps
Environment temperature
Storage temperature
Air relative humidity
Max. altitude:

1.2 Protections

The panel is self-protected and protects the electropumps against:

overloads and excess temperature with automatic reset,

short circuits with fuses (only Plus model),

excess currents in pumps (overload protection),

abnormal voltages,

lack of phase and thermal protection KK,

dry operation,

rapid starts,

faults of the pressure sensor,

inconsistency of floats and/or probes,

blocking of the pumps.
ENGLISH
E.box Plus
E.box Plus D
3 x 400V
3 x 230 V
1 x 230V
50/60Hz
IP 55
1 or 2
12A
5.5kW at 3 x
400V
3.2kW at 3 x
230V
2.2kW at 1x230V
-10 ÷ 40°C
-25°C ÷ 55°C
50% at 40°C
90% at 20
1000 m (a.s.l.)

Table 1: Technical data

68
E.box Basic
E.box Basic D
1 x 230V
50/60Hz
IP55
1 or 2
12A
2.2kW at 1 x
230V
10 ÷ 40°C
-25°C ÷ 55°C
50% at 40
90% at 20
1000 m (a.s.l.)
