Operating instructions
US
FC
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
ESM
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate
PTB
radio frequency energy and, if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
TR
However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference
RU
to radio or television reception, which can be
determined by turning the equipment off and on,
UK
the user is encouraged to try to correct the
interference by one or more of the following
measures:
VIE
– Re-orient or relocate the receiving antenna.
– Increase the separation between the equipment
and receiver.
HE
– Connect the equipment to an outlet in a different
circuit from the one where the receiver is.
– Consult the dealer or an experienced radio/
AR
TV technician for help.
Changes or modifications not expressly approved
by the manufacturer could void the user's authority
JPN
to operate the equipment under FCC rules.
KOR
CHT
THA
4
Observe the following instructions and
recommendations in order to ensure
uninterrupted charging with the charger:
– When installing the new electrical socket, select
an industrial electrical outlet with the highest
possible power available (adapted to the
domestic electrical installation) and have it
commissioned by a qualified electrician.
Porsche recommends an authorized Porsche
dealer, as they have trained technicians and
the necessary parts and tools.
– Where technically possible and legally
permissible, the electrical installation must be
dimensioned in such a way that the maximum
nominal power of the electrical socket used is
available for charging the vehicle.
– Before installation, check that the necessary
power for charging a vehicle can be continuously
provided by the currently available domestic
installation. Protect the domestic installation
with an energy management system,
if necessary.
– The charger must preferably be operated in
earthed power grids. The ground wire must be
correctly installed.
– If you are unsure about the electrical domestic
installation, have it checked by a qualified
electrician. Porsche recommends that you use
a certified Porsche service partner.
– If you intend to use the charger with
a photovoltaic system, contact an authorized
Porsche dealer.
– In order to fully exploit the performance of the
charger and to ensure fast vehicle charging, use
either NEMA electrical sockets with the highest
possible current rating appropriate for the power
plug or industrial electrical outlets according to
IEC 60309.
– When charging the high-voltage battery via
the domestic/industrial electrical outlet,
the electrical installation may be loaded to its
maximum capacity. Porsche recommends that
you have the electrical installations used for
charging checked regularly by a qualified
electrician. Ask a qualified electrician which
inspection intervals are appropriate for
the installation. Porsche recommends that you
use a certified Porsche service partner.
– On delivery, the charging current is automatically
limited to prevent overheating of the electrical
installation. Have a qualified electrician put
the charger into operation and set the charging
current limit as required for the domestic
installation.
f Please see chapter "Charging current limiting" on
page 11.

Grounding instructions

The charger must be grounded.
If it should malfunction or break down, grounding
provides a path of least resistance for electric current
to reduce the risk of electric shock.
The charger is equipped with a cord with an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
