InSpectra StO
™
The System Check provides a method to quickly check the function of the monitor and its optical cable to
accurately calculate the InSpectra StO
• I f the InSpectra StO
™
perform a System Check to verify that your InSpectra StO
specifications. (See InSpectra StO
• I t is recommended the System Check be used whenever damage is suspected to the InSpectra StO
Tissue Oxygenation Monitor or optical cable.
• T he System Check values for the InSpectra StO
historical data.

Battery

A lithium ion battery is installed in the InSpectra

NotE: To ensure maximum battery runtime it is recommended to fully charge the battery:
• U pon receipt of the InSpectra StO
• I f the battery has not been fully charged in the past 30 days.
• T he battery is specified for a minimum of two (2) hours of use when fully charged.
• R eplacement every two years by a qualified service technician is recommended.
To operate on battery power:
1. Unplug the AC cable, if the InSpectra StO
is running currently.
2. Push the ON (top) portion of the ON/OFF button on
the back of the monitor to turn power on.
A sequence of beeps lasting about 30 seconds will
sound indicating a successful power-on self-test.
The LCD screen will illuminate.
1
The hour clock in the left corner of the status
2
bar (top) on the LCD screen will appear.
The battery charge indicator appears in the
3
right corner of the status bar.

NotE:
• T o ensure continuous monitoring, connect to AC power immediately when the battery charge indicator
shows one red bar remaining.
• T o extend battery runtime, ensure full charge as indicated by the green indicator light
indicator bars and decrease the LCD brightness. [see Main Menu (Home), page 13]
3

Fan

The internal fan is used for cooling when charging the battery using AC power. The fan:
• Does not run on battery power.
• Runs continuously when the monitor is operating on AC power.
• Draws air for cooling through the inlet grill on the bottom of the monitor.
cautIoN: Do not block the inlet grill on the bottom of the monitor when plugged into AC power as this may
cause the monitor to overheat.
System Check
2
System Measurement and THI.
2
Tissue Oxygenation Monitor was used during X-ray or Computerized Tomography,
2
System Check section, page 28)
2
StO
™
Tissue Oxygenation Monitor.
2
System
2
System is reading within the stated
2
Measurement and THI will not be recorded to the
2
Tissue Oxygenation Monitor at the factory.
2
2
2
1
3
4
figure 11.1
3
or the full battery
4
11
