DESCRIPTION

Description of the control area
(See Fig. D)
1. Meter and control panel
2. Indicator light panel
3. Lifted hopper warning light (red)
4. High beam indicator light
5. Running light indicator light
6. Turn signal indicator light
7. Battery warning light
8. Engine oil pressure warning light
9. Check engine warning light (high temperature)
10. Hydraulic system oil high temperature and hydraulic
system fault warning light
11. Glow plug pre-heating warning light
12. Parking brake warning light
13. Clogged engine air fi lter warning light
14. Water-in-fuel warning light
15. Display scroll button
16. 3rd broom working light switch
17. Display (*)
18. Left vent
19. Ceiling light: If pressed on the right or left side, it turns on,
in central position, it turns off.
20. Hazard warning light switch
21. Hopper door opening/closing switch
22. 3rd broom tilting switch
23. Right vent
24. Ignition key
25. 3rd broom rotation direction selector
26. Drive pedal
27. Dust control system water pump switch:
• When the switch is turned to the fi rst position, the
nozzles sprinkle a medium quantity of water
• When the switch is turned to the second position, the
nozzles sprinkle the maximum quantity of water
28. Steering wheel
29. Side brooms/suction fan (fi rst position) and 3rd broom
(second position) switch
30. Suction fan/optional equipment switch
31. Brake pedal
32. Windscreen wiper fl uid tank
8
INSTRUCTIONS FOR USE
33018312(3)2010-01
33. Windscreen wiper switch
• In 0 position: windscreen wiper stopped
• In 1 position: windscreen wiper moving
• In 2 position (with spring-return): windscreen washer jet
34. 3rd broom arm extension shifting switch (with spring-
return)
35. Combination switch (**)
36. Suction inlet, brooms, hopper joystick
37. Suction inlet and side broom lowering push-button
38. Suction inlet and side broom lifting push-button
39. Hopper return push-button
40. Hopper dumping push-button
41. Suction inlet and side broom left shifting push-button
42. Suction inlet and side broom right shifting push-button
43. Hopper lifting push-button
44. Hopper lowering push-button
45. Safety push-button (press and hold it to enable the other
push-buttons on the joystick)
46. 3rd broom joystick, to activate the following functions (after
pressing the 3rd broom switch):
• Forward: 3rd broom lowering
• Backward: 3rd broom lifting
• Right side: arm to the right side
• Left side: arm to the left side
47. Skirt lifting push-button
48. Skirt lowering push-button
49. Warning decal
50. Closed hopper door warning light
51. Salt spreader enabling switch
52. Snow brush enabling switch
53. Emergency push-button
(*) See the display functions below.
(**) See the combination switch functions below.
