BEZZERA ARCADIA BREWING PROFILE
MOD.

3 - DESCRIPTION OF MACHINE

3.1 Description of operating cycle

Water is pumped from the mains by an electric pump and fills the boiler. The water coming from the wa-
ter network, by means of a pressure regulator, reaches the magnetic drive pumps and through pressure
relief valves set at 12 bar (1.2 MPa) it charges the exchangers. The boiler water, heated by a heating
element, in turn heats the water in the exchanger, from which, by means of an electrically controlled
valve, it allows it to pass through for infusion of the coffee.

3.2 Description of commands

(Fig. 01 - Fig. 09)
1 Steam knob
2a Keypad for steam output
2b Keypad for coffee output
2c Keypad for coffee output
2d Keypad for water output
3 Steam wand
4 Hot water tap
5 Boiler drain plug
6 Filter holder
7 Automatic steam wand
8 Touchscreen display
9 Machine power on switch
10 Blind filter
11 1 cup filter
12 2 cup filter

3.3 Technical data

The ARCADIA BREWING PROFILE espresso coffee maker is built in 1 to 3 group versions.
The 2 group version is described in this booklet; however, the instructions for use and the layout of the
controls are the same for the other versions.
The A-weighted sound pressure level of the coffee machine is less than 70dB.
Power supply
Heating element
Nominal power
Heating element
Power supply
Heating element
Nominal power
Heating element
Width "A"
Depth "B"
Height "C"
Net weight
Gross weight (pallets)
Water input connector
Drain connector
(Fig. 02)
ARCADIA
1 GROUP
V~/Hz
V~
W 1800
W 1400
V~/Hz
V~
W 2400
W 2000
mm 644
mm 565
mm 525
kg 54
kg 67

3.2.1 Description of command panels

(Fig. 06)
a Steam key 3
b Seam key 2
c Steam key 1
d Pre-selection key for long coffee
e Pre-selection key for regular coffee
f Key for continuous/stop output
g Pre-selection key for double dose of regular
coffee
h Pre-selection key for double dose of long cof-
fee
i Water key 1
l Water key 2
m Water key 3
ARCADIA
2 GROUPS
110 - 120 / 50-60Hz
110
3250
2600
220 - 415 / 50-60 Hz
220-240
3600
3000
824
565
525
67
82
G 3/8"
G 3/4"
42
ARCADIA
3 GROUPS
3800
3000
5800
5000
1034
565
525
82
98
