18-3 Health and Age Restrictions
IMPORTANT!
In Europe the pyrotechnic directive (2007/23) prohibits the sale of
pyrotechnic articles to anyone under the age of 18.
WARNING! The Tech-Air® Race airbag system in Street Mode must not be handled
by children at any time.
WARNING! In event of a crash, the inflation of the airbag will cause sudden
pressure across the back and torso. This can cause discomfort and for users in
poor health this may cause complications.
WARNING! The Tech-Air® Race airbag system in Street Mode must not be used by
persons with a history of heart problems, or other diseases, conditions, afflictions
or illnesses which may weaken the heart.
WARNING! The Tech-Air® Race airbag system in Street Mode must not be used by
persons fitted with a pacemaker or other implanted electronic medical devices.
Note also that magnets are contained inside the activation flap (18).
WARNING! The Tech-Air® Race airbag system in Street Mode must not be used by
persons with neck or back problems.
WARNING! The Tech-Air® Race airbag system in Street Mode must not be used by
women during pregnancy.
WARNING! The Tech-Air® Race airbag system in Street Mode must not be used by
women with artificial breast implants.
WARNING! Any body piercings which coincide with the airbag coverage area
should be removed before electing to use the Tech-Air® Race airbag system in
Street Mode, as inflation of the airbag into and against the body piercings may
cause discomfort and/or injury.
Allergy Advice
Persons with certain skin allergies to synthetic, rubber or plastic materials, should monitor
carefully their skin each time the Tech-Air® Race airbag system in Street Mode is worn. If
any irritation of the skin occurs, immediately stop wearing the system and seek medical
advice and/or attention.
24 EN
RACE
18-4 Transportation of Objects inside the compatible
airbag garment
See section 10.

18-5 Battery Charging

See section 11.
18-6 Operation
Turning On
The operation to turn on the garment is the same as outlined in section 12.
Stability Check (Only in Street Mode)
During the first 20-60 seconds after the system is activated, the system remains disarmed
while it performs a stability check with a flashing green indication (11a). During this period
the system is looking for the body to conduct one or all of the following activities:
• Walking (including up and down stairs)
• Mounting the motorcycle
• Riding the motorcycle
If the check is passed a solid green indication will be given (11a).
Note that the following activities are unlikely to pass the stability check:
• Closing the activation flaps without wearing the suit
• Standing still
• Running or other dynamic actions (such as sharp changes of direction or speed when
walking)
• Sitting down – INCLUDING on the motorcycle with the engine at idle
If after 60 seconds the system cannot see stable use it will give an error indication
by illuminating a single red indicator light (11c) in the LED Display (11). In this case the
garment must be unzipped and closed again to restart the stability check.
WARNING! you MUST ALWAYS check the LED Display (11) after the Stability Check
to confirm you have the solid green LED before starting to ride/using the Tech-
Air® airbag system. The system will not deploy if needed while the 20-60 second
Stability Check is proceeding and will not deploy if needed unless the Stability
Check registers no errors in the system, as indicated by a solid green indicator
light (11a).
RACE
25 EN
