Table B.E DC Bus Inductors
Input Voltage kW
240V 50/60 Hz 5.5
3-Phase
7.5
480V 50/60 Hz 5.5
3-Phase
7.5
(1)
Use MTE RB Series or equivalent inductors.
Table B.F EMC Line Filters
Drive Ratings
Input Voltage
120V 50/60 Hz
1-Phase
240V 50/60 Hz
1-Phase
240V 50/60 Hz
3-Phase
480V 50/60 Hz
3-Phase
(1)
This filter is suitable for use with a cable length of at least 10 meters (33 feet) for Class A and 1
meter for Class B environments.
(2)
These ratings can be ordered with internal "S Type" filters. Refer to the Catalog Number
explanation on page P-4
(3)
Filter must be Series B or later.
(4)
This filter is suitable for use with a cable length of at least 100 meters for Class A and 5 meters for
Class B environments.
Accessories and Dimensions
HP Amps
7.5 32
10.0 40
7.5 18
10.0 25
S Type Filter
kW HP Catalog Number
0.4 0.5 –
0.75 1.0 –
1.1 1.5 –
(2)
0.4 0.5
(2)
0.75 1.0
(2)
1.5 2.0
(2)
2.2 3.0
0.4 0.5 22-RF021-BS
0.75 1.0 22-RF021-BS
1.5 2.0 22-RF021-BS
2.2 3.0 22-RF021-BS
3.7 5.0 22-RF021-BS
5.5 7.5 22-RF034-CS
7.5 10.0 22-RF034-CS
0.4 0.5 22-RF012-BS
0.75 1.0 22-RF012-BS
1.5 2.0 22-RF012-BS
2.2 3.0 22-RF012-BS
4.0 5.0 22-RF012-BS
5.5 7.5 22-RF018-CS
7.5 10.0 22-RF018-CS
and Table B.B for details.
Inductance MTE Catalog Number
0.85 mh 32RB001
0.5 mh 40RB001
3.75 mh 18RB004
4.0 mh 25RB005
L Type Filter
(1)
Catalog Number
22-RF018-BL
22-RF018-BL
22-RF018-BL
22-RF018-BL
22-RF018-BL
22-RF018-BL
22-RF025-CL
(3)
22-RF021-BL
(3)
22-RF021-BL
(3)
22-RF021-BL
(3)
22-RF021-BL
(3)
22-RF021-BL
22-RF034-CL
22-RF034-CL
22-RF012-BL
22-RF012-BL
22-RF012-BL
22-RF012-BL
22-RF012-BL
22-RF018-CL
22-RF018-CL
B-3
(1)
(4)
