P P l l a a y y b b a a c c k k o o f f R R e e c c o o r r d d e e d d V V i i d d e e o o s s
Within the Playback screen, the V V i i d d e e o o s s tab on the right side of the screen allows review and
annotation of previously captured videos.
4
6
1. To browse videos: Press the P P r r i i m m a a r r y y button to choose Primary or Secondary and browse
videos recorded on Channel 1 (primary) or Channel 2 (secondary).
2. Press the arrows on either side of the center preview screen to scroll through captured videos
one at a time. Each video is identified in the top left corner by the channel and order in which it
was captured. Primary channel videos are identified with a "P" and Secondary channel videos
are identified with an "S."
3. Press the arrows on either side of the bottom panel of videos to scroll through the album five
videos at a time.
4. Tap an image 2 times from the bottom panel of images to see the corresponding video on the
center preview screen.
5. To playback videos: Press the P P l l a a y y and S S t t o o p p buttons to control the video in the center
preview pane.
6. To select videos: Press any video to choose it. Selected videos are identified by a green
border. Deselect a video by pressing it again.
7. Press the S S e e l l e e c c t t N N o o n n e e
deselect all images in the album.
P23566L
1
button to switch between Select All and Select None to select or
2
5
7
3
47 EN
