TECHNICAL DATA

Device compliant with
Regulation (EU) 2017/745
Classification under the IEC/EN 60601-1
Essential performance
Appliance for intermittent operation
Power Supply
Max. Power Consumption
Fuses
Water supply:
Air supply:
Operating Conditions
Transport and Storage Conditions
(Excluding Powders)
Altitude
Weights and dimensions
Table 5 – Technical Data
a) W = width ; L = length ; H = height
TECHNICAL DATA
Class lla
I
Parts applied: type B (insert)
IP 20 (appliance)
IP 22 (pedal model FS-05)
According to the standard IEC 80601-2-60
the device has no essential performance
55sec. ON - 30sec. OFF with irrigation
(ULTRASOUND function and POLISHING
function)
30sec. ON - 120sec. OFF without
irrigation (mode: "endo" and "perio/
scaler" power from 1 to 5, "restorative"
power from 1 to 4).
100-240 V~ 50/60 Hz
90 VA
Type 5 x 20 mm, T 2AL, 250V
Working pressure from 1 to 6 bar.
Polisher and scaler part water circuit
cleaning function - See
40 .
Connection via the supplied hose with
quick coupling through an incorporated
and removable filter.
Inlet pressure between 4 and 8 bar.
Air circuit cleaning function - See
9.3 on page 101
Connection via the supplied hose with
quick coupling through an incorporated
filter and pressure reducer.
from 10°C to +35°C
Relative humidity from 30% to 75%
Air pressure P: 800hPa/1060hPa
from -10°C to +60°C
Relative humidity from 10% to 90%
Air pressure P: 500hPa/1060hPa
lower than or equal to 2000 metres
4.8Kg
410 x 260 x 145 mm (L x W x H)
Chapter 6 on page
Chapter
a)
103
