As HyperDecks must buffer a couple of frames before commencing playback, the actual cut will
be delayed a preset number of frames to ensure a clean transition. This is just like setting a
preroll on a videotape machine. You can adjust the length of this delay by changing the number
in the 'offset' box. We've found that five frames usually ensures a clean cut.
If you want to cue to a still frame of video or manually trigger video playback on your
HyperDeck, you can also deselect the 'auto roll' feature.

Controlling HyperDecks with ATEM Software Control

To control the HyperDecks connected to your switcher, click the 'media player' tab in the
software control panel, and choose the 'HyperDecks' palette.
Here you can choose between each of the HyperDecks connected to your system by clicking
one of the four buttons along the top of the panel. These are named according to the labels
entered in ATEM settings. Available HyperDecks are shown with white text, while the
HyperDeck you are currently controlling is shown in orange.
In addition to the text color, each HyperDeck's selection button also has a tally indicator.
Green Outline Indicates a HyperDeck that is currently switched to the preview output.
Red Outline Indicates a HyperDeck that is currently switched to the program output,
meaning it is currently live to air.
You may also see one of the following status indicators above the selection
buttons for your HyperDecks.
Ready HyperDeck is set to remote and a disk is inserted. It is ready for playback and
recording if space is available.
Record HyperDeck is currently recording.
No Disk HyperDeck has no disk inserted.
Local HyperDeck is not set to 'remote' and cannot currently be controlled by your
ATEM switcher.
Choose from up to four
HyperDecks by clicking
their selection
buttons in the
HyperDecks palette
HyperDeck Control 124
